1FK7061-4CH71-1BA0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$1,879.26
The SIEMENS 1FK7061-4CH71-1BA0 SIMOTICS S synchronous motor delivers 2 kW power and 6.4 Nm torque at 4500 rpm, featuring a 24-bit absolute encoder, rotatable flange, and IP64 protection for versatile industrial applications.
1FK7061-4CH71-1BA0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS 1FK7061-4CH71-1BA0 SIMOTICS S synchronous motor represents a high-performance solution for industrial automation systems, offering exceptional efficiency and versatility. This compact permanent-magnet motor delivers a rated power of 2 kW with a rated torque of 6.4 Nm at 4500 rpm, making it ideal for demanding machine applications that require precise motion control. Designed for naturally cooled operation, this motor dissipates heat efficiently through its surface, eliminating the need for external cooling and reducing installation complexity.
The SIMOTICS S-1FK7 series combines advanced technology and robust design to meet the requirements of modern machinery. With a rotatable flange, absolute encoder with 24-bit resolution, and integrated CLIQ drive interface (encoder AS24DQI), this motor ensures high-precision speed and position control. The shaft comes with a fitted key and tolerance N, providing reliable mechanical coupling for various industrial drives. Its IP64 degree of protection guarantees operation in challenging environments, safeguarding internal components from dust and moisture.
Overview
SIMOTICS S-1FK7 motors are designed to offer exceptional adaptability for a wide range of industrial applications. The compact design allows for space-saving installation without compromising performance. Compatible with SINAMICS S120/S220 drive systems, these motors create a highly functional system capable of meeting complex automation demands. Depending on the application, integrated encoder systems for speed and position control can be selected, allowing for tailored motion solutions with minimal setup and calibration.
Benefits
- High power density for space-efficient integration in machines
- Universal suitability across diverse industrial applications
- Available in a wide range of sizes and variants to match system requirements
- High dynamic response due to low rotor moment of inertia for precision applications
- Robust closed-loop control for applications with high or variable load inertia
- Reduced commissioning and disturbance compensation overhead
Applications
- Machine tools requiring precise motion control
- Robots and automated handling systems
- Woodworking, glass, ceramics, and stone processing equipment
- Packaging, plastics, and textile machinery
- Printing machines and auxiliary axes for industrial automation
Download
Product Code: 1FK7061-4CH71-1BA0 —
View Siemens Product Page
More siemens products at Turll.com
| Weight | 9.501 kg |
|---|
