1FK7061-4CH71-1BH1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$2,134.54
High-precision SIEMENS SIMOTICS S 1FK7061-4CH71-1BH1 synchronous motor built for reliable motion control, offering stable torque, advanced encoder performance, and rugged construction.
1FK7061-4CH71-1BH1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS 1FK7061-4CH71-1BH1 SIMOTICS S motor is engineered to deliver dependable performance in a wide range of industrial automation systems. Part of the renowned SIMOTICS S-1FK7 High Dynamic line, this motor provides precise motion characteristics supported by permanent-magnet technology and a robust design that ensures stability even under demanding load conditions. With a nominal power rating of 2 kW, 6.4 Nm of torque, and speeds reaching 4500 rpm, it brings consistent reliability to applications where accurate movement and fast response are critical.
Equipped with a natural cooling system, the motor achieves efficient thermal balance without the need for external components. The integrated 24-bit single-turn absolute encoder with DRIVE-CLiQ interface enables advanced feedback for position and speed control, helping maintain smooth operation in high-performance machines. Its plain shaft with tolerance class N offers mechanical precision, while the built-in holding brake supports secure static positioning. The IMB 5 construction and flange type 1 mounting arrangement further simplify integration in a variety of machine designs. With an IP65 protection rating, the motor withstands challenging environments where dust and moisture are present.
Overview
The SIMOTICS S-1FK7 series is known for compact dimensions, flexible configurations, and a wide selection of variants. This versatility allows these motors to adapt easily to numerous automation tasks while meeting increasing performance expectations in modern industrial machinery. When paired with SINAMICS S120 or S220 drive systems, the result is a responsive and efficient control architecture with high accuracy and dynamic capability. Their integrated encoder options make them suitable for precise motion control in complex operational environments.
These motors are designed to operate without additional cooling equipment, dissipating heat effectively through their external surfaces. Their high overload tolerance also makes them suitable for variable load profiles where peak performance must be maintained.
Design & Key Features
- Compact permanent-magnet synchronous motor with high power density
- Absolute 24-bit encoder (AS24DQI) with DRIVE-CLiQ communication
- Plain shaft with tolerance class N for accurate mechanical interfacing
- Holding brake for secure holding force during standstill
- Protection class IP65 for demanding industrial conditions
- High Dynamic rotor design for rapid acceleration
- Flexible IMB 5 mounting and flange 1 configuration
Download
Product Code: 1FK7061-4CH71-1BH1
More Siemens products at Turll.com
| Weight | 9.8 kg |
|---|
