1FK7061-4CH71-1BH2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7061-4CH71-1BH2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7061-4CH71-1BH2 motor is a high-performance synchronous drive engineered for precision-focused automation environments that demand excellent stability, dynamic behavior, and mechanical durability. As part of the well-known SIMOTICS S-1FK7 High Dynamic series, this model offers efficient operation with a rated power of 2 kW, steady torque delivery of 6.4 Nm, and operational speed reaching 4500 rpm. The naturally cooled design supports long-term reliability, while its compact IMB 5 configuration provides straightforward integration into a wide variety of industrial systems.

This motor is equipped with a rotatable power connector and an advanced 24-bit single-turn encoder utilizing the DRIVE-CLiQ interface. The encoder ensures highly accurate position and speed feedback, contributing to improved responsiveness and performance in demanding automation tasks. A robust plain shaft with tolerance class N enhances mechanical balance, while the integrated holding brake adds secure static positioning capability. With its IP65/IP67 protection level, the motor remains resilient in challenging operating environments, reinforcing its suitability for continuous high-demand conditions.

Overview

SIMOTICS S-1FK7 motors are widely recognized for their compact size, versatility, and outstanding dynamic characteristics. Their modular configuration allows seamless adaptation for various application requirements through selectable encoders, gear options, and mechanical variants. When paired with SINAMICS S120 or S220 drive systems, these motors form a high-performance motion control solution suitable for precise and efficient operation.

With their optimized thermal characteristics, high overload capability, and finely tuned control properties, SIMOTICS S-1FK7 units deliver stable and reliable behavior across a wide spectrum of industrial segments.

Design & Key Features

• High dynamic permanent-magnet synchronous motor
• Absolute encoder AS24DQI, 24-bit, DRIVE-CLiQ interface
• Rotatable power connector for flexible installation
• Plain shaft with tolerance class N
• Holding brake for secure load retention
• Protection class IP65/IP67 for harsh environments
• Efficient thermal dissipation through natural convection

Download

Data Sheet (PDF)

Product Code: 1FK7061-4CH71-1BH2
