1FK7061-4CH71-1CG2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7061-4CH71-1CG2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7061-4CH71-1CG2 SIMOTICS S motor is engineered to deliver precise, stable, and efficient motion performance for a broad range of industrial tasks. As part of the High Dynamic series, this synchronous motor incorporates advanced permanent-magnet technology that ensures responsive acceleration, controlled deceleration, and smooth operation across various load conditions. Its nominal torque of 6.4 Nm and speed of 4500 rpm support demanding automation environments where accuracy and reliability are essential. Natural cooling and a robust mechanical structure provide dependable thermal behavior, while the IP65/IP67-rated enclosure enhances durability in challenging workspaces.

This model features a rotatable power connector and a sophisticated AM24DQI absolute encoder offering 24-bit single-turn and 12-bit multi-turn resolution. This ensures highly accurate position feedback suitable for applications that require both short-term precision and long-range positioning information. The plain shaft design offers versatility for systems requiring low-backlash coupling or custom connection interfaces. The absence of a holding brake allows the motor to operate with reduced inertia in applications where free running or external braking systems are preferred.

Overview

SIMOTICS S-1FK7 motors provide a compact and efficient solution for modern automated machinery. Their modular design, wide range of available encoders, and compatibility with SINAMICS S120/S220 drive systems make them adaptable for diverse environments. These motors are engineered for operation without external cooling devices, allowing heat to dissipate naturally across the housing for stable performance in continuous or dynamic duty cycles. High overload capacity further enhances their suitability for rigorous industrial applications.

Design & Key Features

• Permanent-magnet synchronous motor with high power density
• Absolute encoder AM24DQI with 24-bit single-turn and 12-bit multi-turn capability
• Rotatable power connector for streamlined installation
• Plain shaft with tolerance class N for flexible coupling integration
• IP65 housing and IP67 flange for enhanced protection
• High dynamic response for advanced motion systems
• Natural cooling for stable and efficient operation

Download

Data Sheet (PDF)

Product Code: 1FK7061-4CH71-1CG2
