1FK7061-4CH71-1CH0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7061-4CH71-1CH0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7061-4CH71-1CH0 SIMOTICS S motor is engineered to deliver high precision and stable performance in demanding industrial environments. With a 2 kW power class, 6.4 Nm torque rating, and a nominal speed of 4500 rpm, it delivers consistent operation across a wide range of automated motion tasks. As part of the 1FK7 High Dynamic series, this model incorporates advanced engineering focused on smooth acceleration, controlled deceleration, and reliable torque response. Its naturally cooled design ensures dependable thermal behavior even in intensive applications, while the sturdy IMB 5 mounting and flange type support straightforward system integration.

This motor is equipped with an AM24DQI absolute encoder featuring 24-bit + 12-bit multiturn resolution and DRIVE-CLiQ compatibility, enabling highly accurate position feedback for applications requiring fine movement control. The plain shaft with tolerance class N ensures smooth coupling with mechanical assemblies, and the integrated holding brake increases stability during stationary operations. With ingress protection rated at IP64, it offers durability under challenging ambient conditions, supporting long-term operational reliability.

Overview

The SIMOTICS S-1FK7 series is developed as a versatile line of permanent-magnet synchronous motors designed for broad industrial use. Their compact dimensions, combined with flexible configuration options, allow machine builders to tailor each unit to specific functional needs. These motors integrate seamlessly with SINAMICS S120 and S220 drive systems, forming an advanced automation architecture with refined speed and position control capabilities.

The series supports applications that demand a balance of dynamic behavior, energy efficiency, and mechanical robustness. With strong overload capacity and excellent heat dissipation characteristics, these motors ensure consistent performance even under varying operational loads.

Design & Key Features

• High-resolution AM24DQI encoder with DRIVE-CLiQ interface
• Efficient natural cooling with stable thermal management
• Robust plain shaft with class N tolerance
• Integrated holding brake for precise static positioning
• IP64 protection for enhanced durability
• Dynamic performance suitable for rapid-response systems
• Compact design for space-optimized installation layouts

Download

Data Sheet (PDF)

Product Code: 1FK7061-4CH71-1CH0
