1FK7061-4CH71-1QB1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7061-4CH71-1QB1 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7061-4CH71-1QB1 SIMOTICS S motor is a high-performance motion component designed for advanced automation systems that demand precision, reliability, and long-term stability. As part of the SIMOTICS S-1FK7 High Dynamic series, this motor offers a strong combination of torque, responsiveness, and robust construction. It delivers a nominal torque of 6.4 Nm, operates at a rated speed of 4500 rpm, and is built for a 2 kW power class. The natural cooling design ensures consistent thermal behavior, helping the motor maintain dependable performance in continuous-operation environments.

This model integrates a rotatable power connector and a 20-bit absolute single-turn encoder featuring DRIVE-CLiQ technology (AS20DQI). The encoder provides accurate feedback for positioning and speed control, enabling seamless integration into modern motion control architectures. With an IMB 5 mounting configuration, flange design, fitted-key shaft, and a built-in holding brake, this motor provides secure installation, stable motion characteristics, and reliable holding capability during standstill operations.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors engineered for a wide range of industrial applications. Their modular design, extended accessory options, and diverse encoder configurations allow them to be adapted to different machine architectures. When paired with SINAMICS S120 or S220 drive systems, these motors form a precise and powerful motion platform capable of high-speed control and exceptional accuracy.

These motors feature high overload capability and effective heat dissipation thanks to their surface-cooled construction. With a combination of durable materials, focused engineering, and integrated intelligence, SIMOTICS S-1FK7 motors support demanding workloads while maintaining stable performance.

Design & Key Features

• 20-bit absolute encoder (AS20DQI) with DRIVE-CLiQ communication
• High Dynamic rotor design for improved acceleration
• Strong power density for compact machine layouts
• Holding brake included for reliable static operation
• IMB 5 mounting with flange type 1 for easy installation
• Protection degree IP65 for resilience in industrial environments
• Adaptable for broad automation and motion control applications

Download

Data Sheet (PDF)

Product Code:1FK7061-4CH71-1QB1
