The SIEMENS 1FK7061-4CH71-1QH1 SIMOTICS S motor is engineered for precision-driven industrial applications that require stable motion performance, reliable torque output, and enhanced operational durability. As part of the SIMOTICS S-1FK7 High Dynamic series, this motor integrates advanced permanent-magnet technology to ensure fast responsiveness and smooth motion control across a wide variety of automation tasks. Its 2 kW rating, 6.4 Nm torque capability, and maximum speed of 4500 rpm provide a balanced combination of efficiency and reliability for demanding production environments.

The design features natural cooling, allowing heat to be dissipated through the motor housing, improving long-term thermal stability without requiring external cooling systems. A rotatable power connector provides flexibility during installation, while the 20-bit single-turn absolute encoder (AS20DQI) with DRIVE-CLiQ interface supports accurate position and speed feedback. The plain shaft with tolerance class N ensures consistent alignment, and the integrated holding brake increases operational safety during stationary conditions. With an IP65 protection rating, this motor is suitable for environments where dust and moisture resistance is essential.

Overview

SIMOTICS S-1FK7 motors are known for their compact structure, broad configurability, and impressive motion performance. These motors are compatible with SINAMICS S120 and S220 drive systems, creating an integrated platform that supports advanced control features for automation, robotics, and high-speed machinery. Their efficient temperature behavior and overload capacity enable them to operate dependably under varying load conditions. Combined with a large selection of encoders and mechanical options, these motors adapt easily to numerous industrial applications.

Design & Key Features

• Compact synchronous motor with high power density
• 20-bit single-turn absolute encoder (AS20DQI) with DRIVE-CLiQ
• Plain shaft, tolerance class N, optimized for precision fit
• Built-in holding brake for secure static positioning
• IP65 protection for harsher industrial environments
• Flexible installation with rotatable power connector
• Natural cooling system for stable heat dissipation

Download

Data Sheet (PDF)

Product Code: 1FK7061-4CH71-1QH1
