1FK7061-4CH71-1RG2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$1,794.25
High-performance SIEMENS SIMOTICS S 1FK7061-4CH71-1RG2 synchronous motor designed for precise motion applications, offering dependable speed control and robust construction.
1FK7061-4CH71-1RG2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS 1FK7061-4CH71-1RG2 SIMOTICS S motor is a high-quality synchronous unit engineered for demanding industrial environments that require a reliable combination of accuracy, smooth performance, and long-term endurance. As part of the SIMOTICS S-1FK7 High Dynamic series, this model is well-suited for modern automation systems where rapid response and consistent torque output are essential. With a rated power of 2 kW, a torque capacity of 6.4 Nm, and a nominal speed of 4500 rpm, the motor delivers stable motion control across a wide range of mechanical loads. Its natural cooling design supports efficient heat dissipation through the motor surface, enabling optimal operation without external cooling systems.
This configuration features a 20-bit + 12-bit multiturn absolute encoder (AM20DQI) with DRIVE-CLiQ interface, enabling precise position monitoring in applications requiring multi-revolution accuracy. The plain shaft with tolerance class N provides smooth rotational characteristics, while the absence of a holding brake allows for reduced resistance in dynamic operations. With its IMB 5 mounting arrangement and rugged IP65/IP67 protection, the motor offers strong resistance against dust, moisture, and challenging industrial environments.
Overview
SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors designed for flexible use across a wide variety of motion applications. Their broad configuration options, including encoder variants and gearbox compatibility, allow them to be easily adapted to different performance requirements. When combined with SINAMICS S120 or S220 drive systems, these motors provide advanced closed-loop control and exceptional precision.
The expanded range of SIMOTICS S-1FK7 motors meets the increasing performance needs of contemporary machinery. Their natural cooling concept ensures dependable temperature behavior, and the high overload capability delivers reserve capacity during demanding operational cycles.
Design & Key Features
- Compact synchronous motor engineered for high dynamic performance
- 20-bit + 12-bit multiturn AM20DQI absolute encoder with DRIVE-CLiQ
- Plain shaft, tolerance class N, for smooth mechanical coupling
- Rotatable power connector for easy cable orientation
- IMB 5 construction and flange type 1 for flexible mounting
- Ingress protection IP65 housing and IP67 drive-end flange
- Ideal for precise, high-speed automation processes
Download
Product Code: 1FK7061-4CH71-1RG2
More Siemens products at Turll.com
| Weight | 9.501 kg |
|---|
