1FK7061-4CH71-1RH0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$1,969.72
High-performance SIEMENS SIMOTICS S 1FK7061-4CH71-1RH0 synchronous motor designed for dynamic automation tasks, offering accurate encoder technology and reliable mechanical design.
1FK7061-4CH71-1RH0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS 1FK7061-4CH71-1RH0 SIMOTICS S motor represents a refined combination of mechanical precision, stable power delivery, and advanced encoder technology. As part of the High Dynamic series within the SIMOTICS S-1FK7 family, this synchronous motor supports applications requiring responsive motion, stable acceleration, and consistent torque output. With a nominal torque of 6.4 Nm, a power rating of 2 kW, and a top speed of 4500 rpm, it delivers dependable performance in automation environments where precision and reliability are essential. Natural cooling ensures operational efficiency without additional external cooling accessories, supporting continuous performance even in demanding industrial cycles.
This model is equipped with the AM20DQI absolute encoder, combining 20-bit resolution with 12-bit multiturn capability and DRIVE-CLiQ communication. This configuration enhances position feedback accuracy and long-term stability in dynamic systems. A rotatable power connector simplifies installation, and the plain shaft with tolerance class N provides steady mechanical engagement for a wide range of machine designs. The integrated holding brake further supports secure positioning when the system is not in motion. With IP64 protection, the motor is suitable for environments where dust protection and splash-resistant construction are required.
Overview
SIMOTICS S-1FK7 motors are compact synchronous motors engineered with permanent-magnet technology to support flexible and efficient machine design. Their wide selection of encoder systems, options, and mechanical configurations enables precise adaptation to a broad spectrum of industrial applications. When paired with SINAMICS S120 or S220 drive systems, these motors deliver high-level closed-loop control for speed and position-critical automation tasks.
These motors feature strong overload capacity, dependable thermal behavior, and smooth operating characteristics, making them a preferred choice for system integrators and machine builders seeking reliable performance with minimal setup complexity.
Design & Key Features
- High Dynamic synchronous motor with robust acceleration characteristics
- Absolute encoder AM20DQI with multiturn function and DRIVE-CLiQ interface
- Plain shaft design with tolerance N for accurate mechanical integration
- Natural cooling concept for quiet, efficient operation
- Holding brake included for secure machine positioning
- Ingress protection IP64 for industrial environments
- Adaptable IMB 5 mounting with flange type 1
Download
Product Code: 1FK7061-4CH71-1RH0
More Siemens products at Turll.com
| Weight | 9.8 kg |
|---|
