1FK7061-4CH71-1RH2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7061-4CH71-1RH2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7061-4CH71-1RH2 SIMOTICS S motor is a premium synchronous motor designed to deliver reliable, accurate, and efficient performance in demanding industrial environments. As part of the highly respected SIMOTICS S-1FK7 High Dynamic series, it offers strong motion capabilities supported by a 2 kW power rating, 6.4 Nm nominal torque, and a top speed of 4500 rpm. This model is engineered for applications that require precise handling, steady acceleration, and exceptional thermal performance. Its naturally cooled design ensures stable operation without external airflow, while the rugged mechanical structure enhances long-term durability under intensive workloads.

A key highlight of this motor is its advanced encoder system. It features an absolute encoder with 20-bit plus 12-bit multiturn resolution using the DRIVE-CLiQ interface, delivering accurate speed and position feedback. Combined with a plain shaft built to tolerance class N and an integrated holding brake, it provides consistent behavior even in applications involving frequent stops or detailed motion sequences. The IP65 protection rating, with the DE flange achieving IP67, reinforces the motor’s suitability for harsh industrial environments.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors designed for universal motion tasks. Their broad range of configurations, encoders, and mechanical variants allows flexible adaptation to the unique requirements of advanced machinery. When paired with the SINAMICS S120 or S220 drive systems, these motors form a powerful motion control solution capable of supporting highly dynamic and precise operations.

This product family stands out for its high power density, wide model range, and excellent overload capacity. The line serves applications in robotics, material handling, metalworking, packaging technology, and other motion-critical sectors.

Design & Key Features

• High Dynamic permanent-magnet synchronous motor
• 20-bit + 12-bit multiturn encoder with DRIVE-CLiQ interface (AM20DQI)
• Plain shaft with tolerance class N
• Integrated holding brake for secure positioning
• Natural cooling for stable and efficient operation
• IP65 protection, DE flange IP67 for harsh environments
• Frame size IMB 5, flange type 1, rotatable power connector

Download

Data Sheet (PDF)

Product Code: 1FK7061-4CH71-1RH2
