High-performance SIEMENS SIMOTICS S 1FK7061-4CH74-1EG1-ZJ09 synchronous motor with precision encoder and planetary gearbox for demanding automated applications.
The SIEMENS 1FK7061-4CH74-1EG1-ZJ09 SIMOTICS S motor is a precision-engineered synchronous motor developed for automated systems that demand reliability, accuracy, and long-term performance. Belonging to the High Dynamic series of the SIMOTICS S-1FK7 family, this model provides responsive operation with outstanding torque characteristics and smooth control behavior. It features a 2 kW power rating, 6.4 Nm continuous torque, and a nominal speed of 4500 r/min, making it suitable for high-speed applications where consistent and stable motion is critical. The natural cooling system increases thermal efficiency, allowing the unit to operate continuously without the need for external cooling devices.
This configuration uses a rotatable power connector and an advanced absolute multi-turn encoder with 2048 S/R resolution plus 4096 revolutions, using the EnDat interface for accurate feedback. The encoder provides refined positioning capability, contributing to reliable motion sequences under varying load conditions. The motor includes a plain shaft with tolerance class N and is supplied without a holding brake, making it particularly suitable for applications that require free-running operation. Protection level IP65 enhances durability in demanding industrial environments.
An integrated ALPHA SP+, SP 100S-MF1 planetary gearbox (1-stage, i = 10) further improves torque transmission and allows smooth, efficient reduction necessary for controlled mechanical movement. This combination increases structural stability and optimizes output for tasks involving repetitive or highly synchronized operations.
SIMOTICS S-1FK7 motors are compact synchronous motors known for their power density and adaptability. A wide selection of gear units, encoder variants, and mechanical configurations enables customization for numerous applications. When paired with SINAMICS S120 or S220 drive systems, these motors form a powerful motion control solution suitable for modern production environments.
Engineered for natural cooling and high overload capability, the 1FK7 series ensures consistent operation across prolonged working cycles and maintains precision under demanding conditions.
Product Code: 1FK7061-4CH74-1EG1-ZJ09
More Siemens products at Turll.com
| SKU / Model | 1FK7061-4CH74-1EG1-ZJ09 |
|---|---|
| Weight | 17.502 kg |
