1FK7062-2AC71-1CG0-ZV40 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7062-2AC71-1CG0-ZV40 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7062-2AC71-1CG0-ZV40 SIMOTICS S synchronous motor is a highly capable solution designed for precision motion tasks that demand stability, responsiveness, and mechanical robustness. Engineered within the 1FK7-CT series, this model delivers a rated power of 1.5 kW and provides a steady torque profile of 8.5 Nm, making it suitable for a broad range of industrial automation environments. Operating at 2000 rpm and utilizing natural cooling, the motor maintains efficient heat dissipation without requiring external airflow systems. Its IMB 5 mounting design and adaptable flange type allow seamless mechanical integration in many machine layouts.

This version includes a rotatable power connector and an advanced AM24DQI encoder system that combines 24-bit single-turn resolution with 12-bit multi-turn capability through the DRIVE-CLiQ interface, enabling precise positioning over extended cycles. A smooth shaft with tolerance class N supports stable rotation even under fluctuating load conditions. This model is supplied without a holding brake, making it ideal for dynamic motion requirements. Additionally, the designated V40 configuration incorporates the ALPHA LP+ LP 120-MO1 planetary gearing system, providing a one-stage reduction ratio of i=5. This gearing solution enhances mechanical efficiency while maintaining compact dimensions.

Overview

SIMOTICS S-1FK7 motors are compact, permanent-magnet synchronous motors tailored for industrial environments that require reliable motion performance. With broad configuration options, multiple encoder variants, and compatible gear units, they can be precisely adapted to modern machinery concepts. When paired with SINAMICS S120 or S220 drive components, the motors form a high-function motion control system capable of delivering smooth regulation, accurate speed control, and efficient torque response.

Their design emphasizes dependable thermal behavior without external cooling devices, and the high overload capability supports demanding duty cycles across diverse sectors such as robotics, packaging lines, machine tools, printing equipment, and specialized material processing systems.

Design & Key Features

• 1.5 kW rated power with consistent 8.5 Nm torque
• Rotatable power connector for flexible installation
• AM24DQI 24-bit + 12-bit multiturn encoder with DRIVE-CLiQ
• Smooth shaft, tolerance class N
• Integrated ALPHA LP+ LP 120-MO1 gearbox, ratio i=5
• Natural cooling for stable thermal performance
• Protection class IP64 for industrial environments

Download

Data Sheet (PDF)

Product Code: 1FK7062-2AC71-1CG0-ZV40
