1FK7062-2AC71-1CG1-ZJ02 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7062-2AC71-1CG1-ZJ02 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7062-2AC71-1CG1-ZJ02 SIMOTICS S motor is an advanced permanent-magnet synchronous motor engineered for precision motion tasks in modern industrial automation. Built within the 1FK7-CT series, this model delivers a nominal torque of 8.5 Nm and a rated speed of 2000 rpm, offering stable and efficient performance for systems requiring smooth rotational control and reliable feedback. Its 1.5 kW class supports a wide range of applications while maintaining high operational consistency. The naturally cooled construction allows efficient thermal dissipation through the motor frame, eliminating the need for external cooling components and enabling reliable operation across demanding duty cycles.

This variant features a rotatable power connector, a sophisticated AM24DQI encoder with 24-bit single-turn and 12-bit multiturn resolution via DRIVE-CLiQ, and a smooth shaft with tolerance class N. The absence of a holding brake supports lower inertia and quieter motion, making it ideal for applications where refined dynamics and stable speed regulation are essential. The IP65 protection rating ensures durability in challenging environments. Additional configuration J02 incorporates the ALPHA SP+ planetary gear unit (SP 100S-MF1), providing a 1-stage reduction of i=4 for enhanced torque delivery and mechanical efficiency.

Overview

SIMOTICS S-1FK7 motors are compact synchronous motors designed for high-accuracy automation solutions. Their configurable options, versatile encoder systems, and compatibility with a broad selection of gear stages allow tailored implementation across various industries. When paired with SINAMICS S120 or S220 drive systems, they form a powerful motion control platform with superior closed-loop characteristics.

These motors are optimized for dynamic behavior, offering strong overload handling, excellent thermal management, and long-term operational reliability. Their wide usability extends across machine tools, robotics, packaging systems, textile machinery, ceramic processing equipment, and multi-axis applications.

Design & Key Features

• Permanent-magnet synchronous motor with compact 1FK7-CT design
• AM24DQI encoder with high-precision multiturn and single-turn feedback
• Smooth shaft, tolerance class N
• ALPHA SP+ planetary gear SP 100S-MF1, 1-stage reduction i=4
• Rotatable power connector for flexible installation
• IP65 protection for industrial environments
• Suitable for universal, dynamic, and inertia-critical applications

Download

Data Sheet (PDF)

Product Code: 1FK7062-2AC71-1CG1-ZJ02
