1FK7062-2AC71-1CH0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7062-2AC71-1CH0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7062-2AC71-1CH0 SIMOTICS S motor is engineered to deliver consistent and efficient performance in applications that require accurate control and reliable torque output. With a rated power of 1.5 kW, this synchronous motor supports a nominal torque of 8.5 Nm and operates at 2000 rpm, making it well suited for advanced automation systems that demand smooth and steady motion characteristics. The naturally cooled construction ensures uninterrupted operation, while its IMB 5 mounting format and flange design allow seamless installation within existing machine architectures.

This motor features a rotatable power connector for simplified wiring layouts, along with a high-resolution multiturn absolute encoder that combines 24-bit single-turn accuracy with an additional 12-bit multiturn capability. The encoder uses the DRIVE-CLiQ interface to ensure high-quality communication with compatible systems, allowing precise positioning and speed feedback. A smooth shaft with tolerance class N, paired with an integrated holding brake, enhances the motor’s ability to maintain stable static positions. The IP64 protection rating offers dependable resistance against dust and splashing water, supporting long service life in challenging industrial environments.

Overview

SIMOTICS S-1FK7 motors are compact, permanent-magnet synchronous motors created to meet the evolving expectations of modern machine builders. Featuring a wide variety of encoder and gearbox options, the series enables tailored configurations for diverse performance requirements. When paired with SINAMICS S120 or S220 drive platforms, these motors form a powerful motion control system offering advanced speed regulation and dependable closed-loop control.

With excellent thermal properties, strong overload capacity, and finely tuned encoder systems, the SIMOTICS S-1FK7 lineup supports a broad spectrum of industrial tasks, ensuring precision and reliability throughout the machine’s operating range.

Design & Key Features

• Permanent-magnet synchronous motor with compact form factor
• Absolute encoder AM24DQI with 24-bit single-turn + 12-bit multiturn capability
• Rotatable power connector for easy integration
• Smooth shaft with tolerance class N
• Integrated holding brake for enhanced positional stability
• Natural cooling for reliable thermal management
• IP64 protection for industrial environments

Download

Data Sheet (PDF)

Product Code: 1FK7062-2AC71-1CH0
