1FK7062-2AC71-1QB0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7062-2AC71-1QB0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7062-2AC71-1QB0 SIMOTICS S motor is engineered to deliver precise motion control and stable performance in modern automated systems. As part of the advanced 1FK7-CT series, this unit supports demanding movement profiles while maintaining smooth and consistent operation. With a rated power of 1.5 kW, a torque level of 8.5 Nm, and a nominal speed of 2000 rpm, it is capable of supporting numerous industrial applications that rely on dependable rotational accuracy. Natural cooling and durable construction enhance the motor’s suitability for environments where long operating cycles, minimal maintenance needs, and reliable power conversion are essential.

The motor includes a 20-bit single-turn absolute encoder featuring the Drive-CLiQ interface, ensuring accurate feedback for controlled positioning. A rotatable power connector increases installation flexibility, while the shaft with feather key provides a secure mechanical connection. The integrated holding brake contributes to secure load management and stable stopping behavior. Built with IMB 5 mounting configuration and Flange 1 design, the unit offers versatile compatibility with various machine layouts. Its IP64 degree of protection provides resilience against dust and splashing, improving operating reliability in complex production settings.

Overview

The SIMOTICS S-1FK7 motor family is recognized for compact design, strong magnetic performance, and a broad selection of variants suitable for multiple industries. Their ability to integrate seamlessly with SINAMICS S120/S220 drive systems allows for responsive control, dynamic motion characteristics, and a high level of stability even under fluctuating loads. These motors also provide efficient heat dissipation, enabling steady performance without additional cooling equipment.

With strong overload handling, precise encoder technology, and modular configuration options, the 1FK7 motors are widely implemented in systems that require consistent positioning and continuous productivity.

Design & Key Features

• Permanent-magnet synchronous motor with compact housing
• 20-bit absolute encoder AS20DQI with Drive-CLiQ communication
• Rotatable power connector for simplified cable alignment
• Shaft with feather key, tolerance class N
• Integrated holding brake for controlled stopping
• Protective rating IP64 against dust and splashing
• IMB 5 construction and Flange 1 mechanical interface

Download

Data Sheet (PDF)

Product Code: 1FK7062-2AC71-1QB0
