1FK7062-2AC71-1QB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$1,823.84
High-quality SIEMENS SIMOTICS S 1FK7062-2AC71-1QB2 synchronous motor engineered for controlled motion, stable torque delivery, and dependable performance in industrial automation.
1FK7062-2AC71-1QB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS 1FK7062-2AC71-1QB2 SIMOTICS S motor is a precision-engineered synchronous motor designed to support modern automation systems that demand reliability, controlled torque output, and steady performance. Belonging to the SIMOTICS S-1FK7 series, this model delivers a nominal power of 1.5 kW and a torque rating of 8.5 Nm, making it a strong choice for industrial machines requiring slow but highly stable rotational motion. Its natural cooling system ensures continuous thermal balance without the need for additional external components, creating a simplified yet effective design that integrates easily into compact installations.
This motor features a single-turn 20-bit absolute encoder with DRIVE-CLiQ interface (AS20DQI), enabling accurate speed and position feedback for motion control applications. The rotatable power connector offers flexible cable routing, while the IMB 5 mounting arrangement supports both vertical and horizontal installation variations. The shaft is equipped with a feather key for secure mechanical coupling, and the included holding brake enhances static positioning capabilities. Its enclosure protection rating of IP65, with the flange area rated at IP67, ensures resilience in environments where dust exposure or moisture are present.
Overview
SIMOTICS S-1FK7 motors are compact synchronous motors built with permanent-magnet technology, designed to adapt to a wide spectrum of industrial requirements. The broad availability of encoder options and gear variants makes them suitable for machine builders who prioritize configurable performance. Their design focuses on strong thermal characteristics, high overload capacity, and consistently smooth behavior under changing load conditions.
These motors can be combined with the SINAMICS S120 or S220 drive platforms to form a versatile control system with advanced functionality. Their encoder systems enable precise speed and position management, supporting automated processes with high accuracy.
Design & Key Features
- Permanent-magnet synchronous motor with compact dimensions
- 1.5 kW power class with 8.5 Nm torque
- 20-bit absolute encoder with DRIVE-CLiQ interface
- Rotatable power connector for flexible installation
- Shaft with feather key, tolerance class N
- Holding brake included for secure static positioning
- High protection level: IP65 motor body, IP67 flange
Download
Product Code: 1FK7062-2AC71-1QB2
More Siemens products at Turll.com
| Weight | 9.4 kg |
|---|
