1FK7062-2AC71-1RA2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7062-2AC71-1RA2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7062-2AC71-1RA2 SIMOTICS S motor is engineered for precision-driven industrial applications that require smooth motion, consistent torque, and durable performance across a wide range of operating conditions. Built within the renowned SIMOTICS S-1FK7 CT family, this synchronous motor combines advanced magnetic design with a robust mechanical structure, ensuring stable output even under demanding workloads. With a power rating of 1.5 kW, a nominal torque of 8.5 Nm, and a nominal speed of 2000 rpm, the motor delivers balanced performance suitable for both medium-load and highly dynamic applications. The naturally cooled design increases operational reliability while maintaining an energy-efficient profile.

This model features a rotatable power connector that simplifies installation, as well as the AM20DQI encoder that provides both 20-bit resolution and 12-bit multiturn capability through DRIVE-CLiQ connectivity. This advanced encoder technology enables exceptional positioning accuracy and responsive feedback control. The shaft with feather key, manufactured with tolerance class N, ensures mechanical stability when integrated into precision equipment. With an ingress protection rating of IP65 and additional IP67 protection at the DE flange, the motor is well-suited for harsh industrial environments.

Overview

SIMOTICS S-1FK7 motors are known for compact dimensions, high efficiency, and adaptability. Their broad configuration options, including multiple encoder variants and gearbox combinations, allow the motors to be optimized for numerous machine concepts. When paired with SINAMICS S120 or S220 drive systems, they form a high-performance automation platform with excellent closed-loop control behavior and enhanced reliability.

These motors are designed for operation without external cooling, and the heat generated during operation is dissipated efficiently through the outer surface. Their strong overload capability and wide torque range make them suitable for continuous industrial operation. With their advanced encoder systems and excellent thermal characteristics, SIMOTICS S-1FK7 motors support modern automation requirements in both speed control and position-critical tasks.

Benefits & Applications

• High power density for compact installation
• Optimized for universal machine applications
• Dynamic behavior and rapid acceleration response
• Stable control characteristics for variable load situations
• Reduced commissioning time with integrated encoder options
• Ideal for machine tools, robotics, material processing, packaging, textiles, and printing systems

Download

Data Sheet (PDF)

Product Code: 1FK7062-2AC71-1RA2
