1FK7062-2AF71-1BA0 SIEMENS Exclusive Synchronous Motor Original Brand New

1FK7062-2AF71-1BA0 SIEMENS Exclusive Synchronous Motor Original Brand New

The 1FK7062-2AF71-1BA0 SIEMENS synchronous motor is a high-performance unit from the SIMOTICS S-1FK7 series, designed for demanding industrial automation tasks that require precision, reliability, and efficiency. This 1.9 kW motor operates at 3000 rpm with a DC link voltage of 600 V, providing consistent torque and stable speed regulation under variable load conditions. Its naturally cooled IMB 5 (IM V1, IM V3) construction ensures efficient heat dissipation without external cooling, maintaining performance during prolonged operation. The compact flange design and rotatable power connector enable easy integration into tight machine layouts, reducing installation complexity and saving valuable space.

Equipped with a single-turn 24-bit absolute encoder (AS24DQI) with DRIVE-CLiQ interface, the 1FK7062-2AF71-1BA0 ensures precise feedback for speed and position control. The motor shaft includes a feather key with tolerance N, enabling reliable torque transmission while maintaining alignment. Its IP64 protection rating safeguards against dust and splashing water, making it suitable for a range of industrial environments. Although this model is supplied without a holding brake, its robust closed-loop control properties provide stability even under dynamic or varying load moments.

SIMOTICS S-1FK7 motors can be combined with SINAMICS S120 or S220 drives to form a high-functionality motion control system. These motors offer a wide range of options including gearboxes, encoders, and performance variants, making them adaptable to various machinery requirements. Benefits include space-saving installation due to high power density, exceptional dynamic response for fast-cycle operations, and minimized commissioning effort. The motors are suitable for machine tools, robotics and handling systems, packaging, plastics, textile, and printing machines, as well as auxiliary axes in modern industrial equipment.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors designed to meet the high standards of modern machine generations. Their flexible configuration allows adaptation to nearly any application. The motors dissipate heat efficiently through the housing and provide high overload capability, ensuring reliable operation in demanding environments.

Key Features

• Compact design with high power density for space-saving installation
• Wide variety of motors and performance variants
• High dynamic response and low rotor inertia
• Robust closed-loop control for variable load moments
• Reduced commissioning effort and minimal optimization requirements

Applications

• Machine tools
• Robotics and handling systems
• Wood, glass, ceramics, and stone processing
• Packaging, plastics, and textile machinery
• Printing machines
• Auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7062-2AF71-1BA0
