6AG1052-2MD08-7BA1 Siemens SIPLUS LOGO! 12/24RCEO Original Brand New

• The space-saving basic versions
• Interface for connecting expansion modules, up to 24 digital inputs, 20 (16) digital outputs, 8 analog inputs and 8 (2) analog outputs can be addressed
• All basic devices with integrated web server for TD-based web pages and/or user-defined web pages
• Enclosure width 72 mm (4 U)
• All basic units with Ethernet interface for communication with LOGO! 8, LOGO! TDE, SIMATIC Controllers, SIMATIC Panels and PCs
• Use of standard micro SD cards

Note:

SIPLUS LOGO! 6/7 versions are not compatible with SIPLUS LOGO! 8.

SIPLUS extreme products are based on SIMATIC standard products. The contents listed here were taken from the respective standard products. SIPLUS extreme-specific information was added.

• Ethernet port
• Relay outputs with max. 10 A output current
• Integrated display field with parameterizable backlight (6 x 16 characters, 3 background colors).
• Integrated operator control panel.
• Integrated EEPROM memory for control program and setpoint values.
• Optional standard micro SD cards
• Integral real-time clock with automatic summer/winter time switchover.
• Backup of the integrated real-time clock for 20 days.
• 8 digital inputs, 4 digital outputs.
• 4 inputs as analog inputs in 12/24 V DC variants (0 to 10 V); inputs can also be used digitally.
• 4 inputs can be used for high-speed counting up to 5 kHz (DC versions only).
• Interface for the connection of expansion modules, up to 24 digital inputs, 20 digital outputs, 8 analog inputs and 8 analog outputs can be addressed.
• Connection of the LOGO! TDE text display via Ethernet.

• Integrated basic and special functions:
  • Basic logic functions:
    AND, OR, NOT, NAND, NOR, XOR, positive/negative pulse edge evaluation.
  • Special functions:
    Timer:
    ON delay, OFF delay, ON/OFF delay, latching ON delay, interval relay/pulse output, interval relay/edge-triggered, incremental encoder, random generator, staircase light switch, comfort switch, weekly timer, annual timer, astronomical clock, stopwatch.
    Counter:
    up/down counter, operating hours counter, threshold switch.
    Analog function blocks:
    arithmetic instruction, analog comparator, analog threshold switch, analog amplifier, analog value monitoring, analog differential threshold switch, analog MUX, analog ramp, PI controller, PWM, analog filter, max/min. mean value.
    Other:
    latching relay, current impulse relay, message text, software switch, sliding/full converter, full/sliding converter, datalog.
• 400 function blocks can be interlinked
• Up to 64 bit memories
  (including restart bit memory, bit memory for controlling the backlight of the integral display and the LOGO! TDE text display, bit memory for switching between 2 parameterizable character sets in the message text).
• Integrated retentivity.
• Password protection.

• Additional know-how protection with the optional micro SD card.

• Data logging to internal memory or micro SD card (up to 20 000 records)
• Macros (user-defined functions) for LOGO! Soft Comfort
• 64 open terminals
• 4 8-bit shift registers
• Extended diagnostic functions
