6AG1331-6SB00-7AY0 SIEMENS SIPLUS LOGO! Power Original Brand New

[ez-toc]

Overview

Thanks to its stepped profile design, the SIPLUS LOGO!Power product family is ideally suited for low installation depths, such as in miniature distribution boards. The stabilized power supplies with a wide-range input of 100 … 240 V AC (85 … 264 V) and 110 ... 300 V DC are available with an output voltage of 24 V in four performance classes. The 24 V versions are ideal for supplying SIPLUS LOGO! PLCs with the corresponding voltage input. The high level of efficiency across the entire load range as well as the low no-load losses result in lower overall energy consumption. Greater convenience when commissioning and servicing thanks to integrated current monitor (for devices at least 36 mm wide). The extended temperature range enables a host of additional applications.

Main product highlights

• 24 V DC / 1.3 A, 2.5 A and 4.0 A
• Narrow unit with width of 36 mm, 54 mm or 72 mm and overall depth of 53 mm in LOGO! design
• Flexible mounting: top hat DIN rail or wall mounting in a range of installation positions
• Higher energy efficiency: up to 90% efficiency over the entire load range as well as no-load power losses of < 0.3 W
• Integrated current monitor: Actual output current measurement directly at the power supply unit (for devices at least 36 mm wide)
• Global use: International certifications such as UL, CSA, FM or ATEX

6AG1331-6SB00-7AY0
