6AG1461-0AA01-2AA0 Siemens SIPLUS S7-400 IM 461-0 RX Original Brand New

Model / SKU6AG1461-0AA01-2AA0

6AG1461-0AA01-2AA0

Siemens SIPLUS S7-400 IM 461-0 RX based on 6ES7461-0AA01-0AA0 with conformal coating, -25…+60 °C,

$2,156.74
Available on backorder
  • ConditionOriginal Brand New
  • Warranty12 months

Backorder available · Factory lead time 2–3 weeks.

Request bulk quoteAsk on WhatsApp
  • Genuine Products
  • Up to 1-Year Warranty
  • Global Shipping
  • Secure Payment
  • PI / Bank Transfer Available
  • Bulk Quote Support

Description

[ez-toc]

Overview

  • Receive interface connection for central extension up to 5 m
  • Transfer from P and K Bus
  • Pluggable in extension device
  • Usable exclusively with IM 460-0
Note:

SIPLUS extreme products are based on SIMATIC standard products. The contents listed here were taken from the respective standard products. SIPLUS extreme specific information was added.

Technical documentation on SIPLUS can be found here:
http://www.siemens.de/siplus-extreme

Application

The IM 461-0 interface module is intended for use as a send IM for central connection over short distances of up to 5 m. It receives data from both the P-bus and the C-bus.

The IM 461-0 interface module is intended for use only in association with the IM 460-0 interface module (in the central controller).

Design

The IM 461-0 interface module can be inserted into the following expansion modules:

  • UR1,
  • UR2,
  • ER1 and
  • ER2.

The module has:

  • 2 LEDs for indicating faults.
  • 1 interface (input) for connecting the 468-1 connecting cable of the upstream interface module.
  • 1 interface (output) for connecting the 468-1 cable to the downstream interface module. At the last interface module on the line, a terminating connector must be plugged into this interface.
  • Coding switch for setting the number of the rack.
  • Battery infeed socket for connecting an external battery when replacing the rack power supply.

6AG1461-0AA01-2AA0

Siemens SIPLUS S7-400 IM 461-0 RX based on 6ES7461-0AA01-0AA0 with conformal coating, -25…+60 °C,

Visit 6AG1461-0AA01-2AA0

For more our products visit turll.com

Specifications

SKU / Model6AG1461-0AA01-2AA0
Weight0.843 kg
Dimensions230 × 300 × 35 mm
