6AV2104-4DD07-0AE0 Siemens SIMATIC WinCC Runtime Advanced Original Brand New

PC-based operator control and monitoring system for single-user systems directly at the machine.

SIMATIC WinCC Runtime Advanced V17 is configured with the configuration software SIMATIC WinCC Advanced V17, SIMATIC WinCC Professional V17, SIMATIC WinCC Advanced V18 or SIMATIC WinCC Professional V18, SIMATIC WinCC Advanced V19 or SIMATIC WinCC Professional V19.

• Functions for all visualization tasks:
  • Operator functions
  • Graphics and trend displays
  • Alarm logging
  • Report system
  • Archiving (option)
  • Recipe management (option)
  • Audit Trail (option)
• Flexible runtime functionality due to Visual Basic scripts
• Service concepts with remote operation, diagnostics and administration via intranet/Internet as well as email communication increase availability (option)
• Support for simple distributed automation solutions based on TCP/IP networks at the machine-level (option)
• Part of the Totally Integrated Automation Portal
  • Direct access to the tag and message configuration of the SIMATIC Controller
  • Excellent support of the new SIMATIC S7-1500 Controller
    With symbolic addressing
    Access to the new memory-optimized data blocks
    New alarm and diagnostics concept (incl. ProDiag)
  • Integrated diagnostic functions for increasing productivity

SIMATIC WinCC Runtime Advanced is the high-performance visualization software for simple, machine-oriented visualization tasks. It can be used as a single-user solution for all automation applications in production automation, process automation and building services automation.

SIMATIC WinCC Runtime Advanced can be used in combination with the following operator panels:

• SIMATIC Rack PC:
  • IPC347, IPC547, IPC647, IPC847
• SIMATIC Box PC:
  • IPC227, IPC427, IPC627, IPC827
• SIMATIC Panel PC:
  • IPC277, IPC477, IPC677, Panel PC Ex OG
• SIMATIC S7 Open Controller: ET 200SP Open Controller
• SINUMERIK PC: PCU 50.3, PCU 50.5
• Standard PCs with resolutions (W x H in pixels) of:
  • 4:3 format: 640 x 480, 800 x 600, 1024 x 768, 1280 x 1024, 1600 x 1200
  • Widescreen format: 800 x 480, 1280 x 800, 1366 x 768, 1440 x 900, 1680 x 1050, 1920 x 1080, 1920 x 1200, 1980 x 1080

SIMATIC WinCC Runtime Advanced is available as a software package with 128, 512, 2 048, 4 096, 8 192 and 16 384 PowerTags.

The term PowerTags is used to identify process tags and area pointers that have a process link to the controller. Tags without process links, constant limit values of tags, and messages (up to 4 000 bit-triggered messages) are also available for additional system performance. The range of functions of WinCC Runtime Advanced includes the centralized HMI components for visualizing and reporting, and it can be expanded to suit requirements and costs by using optional packages.

SIMATIC WinCC Runtime Advanced is configured with the SIMATIC WinCC Advanced or SIMATIC WinCC Professional configuration software.

Visualization via Windows-compliant user interface

Made up of parameterizable screen objects and faceplates created on a project-specific basis:

• Numeric and alphanumeric input/output fields
• Static text and graphic display plus vector graphics
• Dynamizable graphics from HMI symbol library
• Bar graph, trend curve graph with scroll and zoom function as well as read line
• Signal-specific text and graphics lists
• Buttons and switches for operator-process communication
• Editing fields for process values (signals)
• Analog display, slider as example for further screen objects
• Project-specific faceplates created from basic objects of the system
• Graphic displays for various standard graphic formats, e.g. bitmaps, .jpg, .wmf

Alarms and messages

• Discrete alarms and analog alarms as well as event-driven Alarm-S/Alarm-D message procedure with SIMATIC S7
• The new ProDiag alarm and diagnostics concept of the S7-1500 Controller is also supported
• Freely-definable message classes for definition of acknowledgment response and display of alarm events

Logging of alarms and process values ¹⁾

• Logging in files (e.g. CSV or TXT file) and Microsoft SQL databases
• Online evaluation of process value and alarm logs
• Evaluation of process value and alarm logs using standard Microsoft tools such as Excel

Recipes ¹⁾

• Generation of data records for machine data or production data
• Display or entry of data records via a configurable screen object or via process screens distributed within the project
• Transmission of data records from or to the PLC
• Import/export of data records from/to CSV files for further processing with other tools (e.g. MS Excel)

Documentation of process data, alarm events, and recipes

• Time or event-driven report output
• User-definable layout

Flexible expansion of integrated system function using Visual Basic script

Language support for multilingual projects

• Up to 32 online languages
• Language-dependent texts and graphics
• Language selection during runtime

User-oriented access protection according to requirements of regulated sectors

• Authentication with user ID and password
• User group-specific rights
• Central system-wide user administration based on SIMATIC Logon¹⁾
• Monitoring of changes by operators in runtime operation¹⁾
• Recording of operator actions in an Audit Trail ¹⁾

Onboard PLC connection to many different PLCs

• Communication via native drivers and standard OPC channel
• Simultaneous connection using several protocols: OPC Client and SIMATIC HMI HTTP protocol are additive, i.e. they can be used in conjunction with other PLC connections

Open communication between HMI systems and with higher-level systems

• OPC Servers
  • Use of the visualization system as a data server (OPC Server) for higher-level automation components, e.g. control systems or systems in the office area
  • OPC DA Server: tags, e.g. process values
• Communication between HMI systems is established on the basis of Ethernet networks, or via the intranet/internet
  • Read and write access to tags. The WinCC Runtime Advanced or SIMATIC Panels provide other SIMATIC HMI systems or office applications with data (tags)
• Sending of emails on demand or event-driven
  • e.g. to maintenance personnel via SMTP server (Simple Mail Transfer Protocol)
  • The optional use of email/SMS gateways enables access to standard networks (external service provider required)
• System diagnostics via device-specific HTML pages. The following functions are available:
  • Starting and stopping the HMI runtime for maintenance
  • Remote access to recipe data records, passwords and information specific to the HMI system
  • Access to the HMI system files via a file explorer
  • Download of configuration data via the intranet/internet
  • Supplement with own HTML pages

WinCC Sm@rtServer for the remote control via the intranet and internet ¹⁾

• Display and control of process screens on remote PC or Panel
• A SIMATIC HMI system can be used to control or monitor another system remotely; entry level for client/server configurations for distributed operator stations or for solutions with head-end stations or control rooms

¹⁾ Option for SIMATIC WinCC Runtime Advanced; runtime licenses must be purchased separately. More information is available under “WinCC options”.
