6AV2107-0UP00-0BH0 Siemens SIMATIC ProDiag Original Brand New
$580.86
6AV2107-0UP00-0BH0
Siemens SIMATIC ProDiag for SIMATIC Comfort/Mobile Panels, Controls for WinCC V14 or higher; runtime software in TIA Portal; single license; license key for download; without software and documentation; class A; – – consignee email address required for delivery
[ez-toc]
Overview
The TIA Portal option ProDiag makes it possible to monitor a machine or plant and to intervene in the event of a fault. The monitoring messages which can be generated for the various faults provide specific information on the monitoring mode, location and cause of the fault. Information on troubleshooting can be provided in addition. Plant operators can then not only recognize faults, they can also identify any potential danger in advance and take appropriate countermeasures.
Licensing
- The runtime license for controllers includes 250 supervisions or an unlimited number of supervisions per CPU. From FW 2.0 onwards, the software can run on S7-1500/ET 200SP CPUs regardless of the TIA Portal version.
- For the visualization of the messages, the controls are licensed according to the HMI runtime platforms.
You can find more information on the Software Update Service, license types, Online Software Delivery and handling your SW licenses with the Automation License Manager under this link.
Benefits
- Automatic code generation in the CPU, without altering the code of the user program
- Message texts are derived automatically from the information existing in the project
- Simple visualization on the HMI by means of prepared controls
- Machine and plant diagnostics without programming device directly on the HMI
Application
SIMATIC ProDiag is the fully-integrated TIA solution for machine and plant diagnostics. It saves the need for programming diagnostics in the CPU during the engineering phase and provides support for troubleshooting on the HMI.
Function
- Central, cycle-exact time stamping of the fault messages
- Automatic generation of the monitoring logic and message calls
- Automatic updating of the SIMATIC HMI when changing the message configuration for 3 languages
- HMI systems do not have to exit runtime mode in the event of changes
- Directly available in the language editors LAD, FBD, SCL and STL
- Monitoring can be parameterized at a later date on F blocks and know-how-protected blocks
- Central definition of message structure for the project
- HMI Control for displaying the current status of the configured ProDiag monitoring functions
- HMI Control for displaying the current status of GRAPH sequencers
- HMI Control for displaying the current program status of a ProDiag message or a GRAPH sequencer
- HMI Control of the faulty operand of the user program
6AV2107-0UP00-0BH0
Siemens SIMATIC ProDiag for SIMATIC Comfort/Mobile Panels, Controls for WinCC V14 or higher; runtime software in TIA Portal; single license; license key for download; without software and documentation; class A; – – consignee email address required for delivery
Visit 6AV2107-0UP00-0BH0
For more our products visit turll.com
| Weight | 0.001 kg |
|---|---|
| Dimensions | 1 × 1 × 1 mm |
