6AV2156-0BP31-7LA0 Siemens SIMATIC WinCC Unified V17 Performance Insight Original Brand New

WinCC Unified Performance Insight

The WinCC Unified Performance Insight can be used to calculate and analyze plant-specific indicators for individual plant units, machines or entire production lines in machine or line-oriented production plants with WinCC Unified PC systems.

Licensing:

A version-specific Runtime basic license is required to use the option.
In addition, every plant object to which a Performance Insight configuration (e.g. KPI, operand) is assigned either directly or via the plant object type is an “analyzed plant object” in the licensing context.

Graded licenses are available for analyzing plant objects. This number can be increased at any time via additive plant objects (countable licenses).
The licenses are divided into 10, 30, 100 and 300 plant objects.

The configuration of Performance Insight in the engineering does not require a license.

Demonstration of weak points in production processes and deriving optimization potential.

• Flexible – individual calculation of plant-specific indicators in WinCC Unified
• Creating relationships – recognizing indicators in context, e.g. availability per shift
• Optimally informed – analyzing indicators in WinCC Unified Runtime as a bar graph, Gantt chart or table even via Web
• Expandable – adding indicators in existing plants without production losses
• Getting results fast – short configuration time and familiarization time thanks to integration in WinCC Unified

All user groups benefit from the Performance Insight, from the application engineer to management-level evaluators.
The engineer can use the application environment integrated in WinCC Unified to derive individual formulas for calculating performance indicators.

KPIs and operands from Performance Insight are automatically created in event- or time-controlled Excel reports and used by management for production analysis and documentation.

For maintenance, the web client of the WinCC Unified can be used for analysis with the bar (for performance), progression (Gantt) and table controls.
Performance indicators can be displayed on local user interfaces using standard WinCC Unified resources to keep machine operators up to date.

Fault analyses provide information about the frequency and duration of machine or plant downtimes. The included controls can be effortlessly integrated in WinCC Unified process pictures.

The determined data gives information on the effectiveness of individual machines and of entire production plants. The transparency of the data allows for a quick response and countermeasures in the event of faults, which increases the availability of the machine. Structuring of the production plant constituting central elements for evaluation (equipment efficiency)

• Can be used for individual machines or even complete production plants
• Easy integration in existing WinCC Unified plants
• Cyclic or event-controlled calculation of indicators (KPIs)

All of the analysis results are integrated in the form of controls in WinCC Unified screens. Bar (performance), trend (Gantt) and table views are available in WinCC Unified process pictures. Complete transparency throughout the machine park as the basis for optimizing plant productivity via automatic execution of reports.

• Recognition of production relationships
• Calculation of downtimes and localization of sources
• Weak-point analysis in production processes.
