6AV6361-1AA01-4AE0 Siemens Process Historian 2014 SP3 Original Brand New

SIMATIC Process Historian

The Process Historian is a high-performance, long-term archiving server solution that stores WinCC process values and messages in a central database. The system offers full scalability for performance and scope: It records and stores data from one or more WinCC, WinCC RT Professional and PCS 7 projects.
The number of connected single stations, servers, or redundant server pairs is unrestricted. SIMATIC Process Historian is designed for use throughout your plant, and is positioned below the corporate management level (ERP, MES).

The SIMATIC Information Server is used as a reporting system for the Process Historian. It accesses the central database of the Process Historian and visualizes the data in clear, user-friendly displays on WinCC stations or office PCs. The central Process Historian database provides access to real-time data throughout the plant.
This data is the key to sustainable plant optimization measures. Since the archive system can be fully integrated, no additional engineering is required. SIMATIC Process Historian uses the integrated relational database, SQL Server from Microsoft®. No complex reconfiguration is needed because the archive system is integrated into WinCC. Selected WinCC process values or messages are archived long-term on a time or event-driven basis.

The Process Historian is used for the long-term archiving of process values and messages.

SIMATIC Process Historian 2014 SP3

• Central, plant-wide long-term archive as corporate information hub
• Real-time archiving of process values and messages from WinCC V7/V8, WinCC RT Professional and WinCC/PerformanceMonitor according to compatibility specifications
• High performance with very large data volumes
• Data access via OPC UA server
• Migration support for data migration from WinCC/ Storage plus, CAS Storage plus and WinCC segments.
• High availability thanks to redundancy concept with observer/witness server for increasing data security
• High degree of security due to integrated, complete backup and restore of all segments (Disaster Recovery)
• Enhanced data security through store and forward mechanism
• Scalable without breaks in production
• Maximum data transparency
• High degree of security thanks to integrated backup system
• Simple and fast management and diagnostics with the Process Historian Management “Dashboard”
• Batch functionality in accordance with PCS 7 specifications

Licenses

• The Basic Package includes the runtime software and the single license for one installation.
• The SIMATIC Process Historian supports archiving of any amount of data.
  The archive data is licensed at the data source, for example, in WinCC systems (archive tags for WinCC V7 or logging tags of WinCC Logging for WinCC Professional RT).
• The redundancy package is required for the redundant Process Historian; existing Basic Package installations can be converted with the redundancy option.
• The OPC UA interface needs a separate license.

You can find more information on the Software Update Service, license types, online software delivery and handling your SW licenses with the Automation License Manager here:
www.siemens.com/simatic-licenses

• Fully integrated archiving solution for large volumes of data
• Central, plant-wide long-term archive as corporate information hub
• Process data and messages from any number of subordinate WinCC systems can be archived
• Plant expansions can be implemented without interrupting the production process
• High availability in redundant mode
• High degree of security due to integrated backup system
• Database for analyses with the aim of optimizing the plant and thereby raising productivity

• Real-time storage of the WinCC archive data (process values and messages) from any number of WinCC stations
• Visualization of the archive data on WinCC clients or WinCC single stations either directly or using the SIMATIC Information Server
• Process Historian configuration tool for fast, simple engineering
• The redundant Process Historian is based on the Microsoft SQL Server Mirroring (3rd system for controlling the availability of the redundancy)
• High degree of security due to integrated complete backup and restore of all segments
• During the initial configuration the database and the segmentation are set up
• The PH-Ready component is installed on the WinCC server for the process of archiving to the PH
• The PH automatically detects all connected WinCC server projects (via the PH-Ready component)
• The Process Historian Management “Dashboard” enables simple and fast management and diagnostics
