6AV6362-1AB00-0AH0 Siemens SIMATIC WinCC/Web Navigator Original Brand New
$2,370.43
6AV6362-1AB00-0AH0
Siemens SIMATIC WinCC/Web Navigator, 1 client license (countable), option for WinCC V7.4 or higher and WinCC Professional V14 or higher, runtime software, single license, license key download – – consignee email address required for delivery
[ez-toc]
Overview
WinCC WebNavigator
- Option for SIMATIC WinCC or WinCC Runtime Professional for operating and monitoring plants over the Internet, company Intranet or LAN.
- Configuration from:
- A web server with SIMATIC WinCC as single-user or server version and a web client that permits operator control and monitoring of a current WinCC project using the Internet Explorer. In combination with WinCC V7, the WebNavigator Server can be operated on a MultiClient
Licenses
- A (server-based) license is required for the WebNavigator. This is a graduated license based on the number of simultaneous web client access operations and can be incremented at any time using additive web client licenses (countable licenses).
- The WebNavigator client software can be installed as many times as required without the need for a license.
- A (client-based) license is required for the WebNavigator diagnostics. This provides access to all web servers with a WebNavigator Server or WebNavigator Diagnostic Server license.
- The WinCC/WebUX and WinCC/WebNavigator licenses can be combined, if necessary.
You can find more information on the Software Update Service, license types, online software delivery and handling your SW licenses with the Automation License Manager here:
http://www.siemens.com/simatic-licenses
Note:
When accessing the operator stations via the WinCC WebNavigator option, suitable protective measures (including IT security such as network segmentation) should be taken in order to ensure safe operation of the system.
You will find more information on the topic of Industrial Security on the Internet at:
http://www.siemens.com/industrialsecurity
Benefits
- Operator control and monitoring across long distances and on different platforms (PC, local panel, mobile PDA)
- Large configurations with up to 150 operator stations (depending on the plant complexity and communication load)
- Optimally tailored clients for operating and monitoring, analysis, service and diagnostics
- Acceptance of configuration data for the web, generally without changes
- Minimum maintenance costs due to central software administration
- With the WinCC Web Viewer (WinCC Viewer RT), the process screens can be displayed on the web client independently of the Internet Explorer. Settings for the client are made on the client itself. The WinCC Web Viewer can also be used in conjunction with the MS Terminal Service.
- The SIMATIC WinCC WebNavigator can also be operated in “view only” mode and is thus used as tool for monitoring and navigating using Internet Explorer or WinCC Web Viewer (WinCC Viewer RT).
- Security is increased by adjustable automatic logout. If an automatic logout is to take place, an absolute or inactive time period can be set.
Application
In addition to the standard WebNavigator licensing, there is the “Diagnostics Client” with identical functionality but different licensing. It is especially suitable for the following applications:
- Remote diagnostics/operation of several unmanned WinCC server stations
- Central control rooms that monitor several web servers via one user interface
- Maintenance personnel who require guaranteed access to the server at any time, regardless of the number of users already logged on to the server.
On the server side, only one WebNavigator Diagnostics Server license or, alternatively, one Standard WebNavigator license is required.
Design
Thin Client solutions
The WebNavigator can also run under Windows Server 2008 R2 SP1 or Windows Server 2012 R2 terminal services.
The Windows Server 2008 R2 SP1 or Windows Server 2012 R2 operating system is required.
This makes it possible, for example, to connect SIMATIC Thin Clients to the WinCC server as visualization stations.
For this purpose, the Windows terminal services must be installed on the PC on which the web client is installed.
The Windows Server 2008 R2 SP1 or Windows Server 2012 R2 operating system is required.
Up to 25 Thin Clients can be connected to one terminal server.
Applications:
- Mobile devices
- Handhelds
- Rugged on-site visualizations
Function
The WinCC basic system makes setting up and configuring a WebNavigator Server very easy. WinCC process screens to be visualized via the Internet are created as usual using the graphic editor.
To display WinCC process screens on the web client, the Microsoft Internet Explorer or supplied browser-independent WinCC Web Viewer (WinCC Viewer RT) is used.
The operator on the web client is integrated in the central WinCC user administration and can operate and monitor the system according to the configured access rights.
The WebNavigator supports all standard security mechanisms that can be used for applications on the Internet, e.g. routers, firewalls and proxy servers.
6AV6362-1AB00-0AH0
Siemens SIMATIC WinCC/Web Navigator, 1 client license (countable), option for WinCC V7.4 or higher and WinCC Professional V14 or higher, runtime software, single license, license key download – – consignee email address required for delivery
Visit 6AV6362-1AB00-0AH0
For more our products visit turll.com
| Weight | 0.001 kg |
|---|---|
| Dimensions | 1 × 1 × 1 mm |
