6AV6646-1BA15-0NA0 Siemens SIMATIC ITC1500 V3 Industrial Thin Client Original Brand New

The SIMATIC ITC Industrial Thin Clients for SINUMERIK support the distributed configuration of the operator panel front and control. Communication in the SINUMERIK system takes place via VNC (Virtual Network Computing) for the remote control of an NCU/IPC.

The operating units are available in display sizes 12", 15", 19", 22" and 24" as capacitive multi-touch devices with glass front.

• SIMATIC ITC1200 – 12" multi-touch, HD‑ready (1280 × 800)
• SIMATIC ITC1500 – 15" multi-touch, HD‑ready (1366 × 768)
• SIMATIC ITC1500 – 15" multi-touch, full HD (1920 × 1080)
• SIMATIC ITC1900 – 19" multi-touch, HD‑ready (1366 × 768)
• SIMATIC ITC1900 – 19" multi-touch, full HD (1920 × 1080)
• SIMATIC ITC2200 – 22" multi-touch, full HD (1920 × 1080)
• SIMATIC ITC2400 – 24" multi-touch, full HD (1920 × 1080)

The operator panel front is secured from the rear using special mounting clips included in the scope of supply.

• Capacitive sensor technology for user-friendly operation
• High-quality design and high degree of ruggedness
• Design of flat operator panels through shallow installation depth and low power dissipation
• Vibration-free mounting of the SIMATIC IPC for SINUMERIK in the control cabinet
• Efficient operation of larger machines using up to 4 additional distributed operator panels simultaneously

The SIMATIC ITC Industrial Thin Clients for SINUMERIK are linked to the IPC/NCU via Industrial Ethernet as a thin client in a dedicated subnet (via DHCP server on the IPC/NCU).

Interfaces:

• 4 × USB 2.0 (rear)
• 2 × Ethernet 10/100/1000 Mbps

For a USB 2.0 interface at the front, a USB extension is available for installation in consoles.

• Signal transmission between operator panel front and IPC/NCU via Industrial Ethernet
• Easy installation assisted by a self-holding mechanism
• The distance to the operator panel fronts is determined by the maximum distance between two network nodes/access points (100 m).

The SIMATIC ITC Industrial Thin Clients for SINUMERIK can be used for:

• SINUMERIK 840D sl from software version 4.8 SP4:
  • NCU 710.3B PN (With ITC2200, only in conjunction with IPC)
  • NCU 720.3B PN/NCU 730.3 PN
• SIMATIC IPC427E for SINUMERIK (PCU‑Basesoftware V12.1 or higher)
• SIMATIC IPC227G for SINUMERIK (PCU‑Basesoftware V12.1 or higher)
• SINUMERIK ONE
  • PPU 1740
  • NCU 1740
  • NCU 1750
  • NCU 1760
