6DR5013-0EG01-0AA0 SIEMENS Exclusive SIPART PS2 Electropneumatic Positioner Original Brand New

6DR5013-0EG01-0AA0 SIEMENS Exclusive SIPART PS2 Electropneumatic Positioner Original Brand New

The SIEMENS 6DR5013-0EG01-0AA0 SIPART PS2 is a smart electropneumatic positioner designed for precise and reliable control of pneumatic linear and part-turn actuators. It operates using a 4...20 mA signal and features non-contacting (wear-free) position detection (NCS), ensuring durability and long-term stability. Housed in a robust aluminum enclosure, it is certified for use in hazardous environments with intrinsic safety (Ex i) compliance.

This version is a single-acting model that includes an Analog Output Module (AOM) for 4...20 mA analog position feedback. The unit offers fail-safe functionality—automatically depressurizing the actuator in case of electrical power failure. It supports expansion via modules like Digital I/O, inductive or mechanical limit switches, and allows for remote mounting for better protection in extreme conditions.

Overview

SIPART PS2 positioners adjust valve positions according to setpoint values on pneumatic valves. They feature intelligent diagnostic capabilities, both online and offline, that enhance reliability and reduce downtime. These functions can be further enhanced with optional pressure sensors.

Design

The SIPART PS2 digital positioner includes:

• Base plate and lid, available with or without inspection window
• Electronics with screw terminals: 4-20 mA, HART, PROFIBUS PA, or FOUNDATION Fieldbus
• Non-contacting sensor (NCS) for position detection
• Pneumatic block with right-side connection ports for air supply and actuating pressure

Optional accessories:

• Analog Output Module (AOM): 4-20 mA position feedback
• Digital I/O Module (DIO): 3 digital outputs and 1 input for alarms and signaling
• Inductive Limit Switches (ILS): NAMUR signal-based limit monitoring
• Mechanical Limit Switches (MLS): physical limit monitoring with fault indicators

Separate Mounting Capability

SIPART PS2 allows separate installation of the positioner and sensor unit, connected electrically and pneumatically. This setup is beneficial in environments with extreme vibration, magnetism, or radiation—keeping the control electronics safe while maintaining measurement accuracy.

Product Code: 6DR5013-0EG01-0AA0
