6DR5023-0NM00-0AA0 SIEMENS Exclusive SIPART PS2 Electropneumatic Positioner Original Brand New

6DR5023-0NM00-0AA0 SIEMENS Exclusive SIPART PS2 Electropneumatic Positioner Original Brand New

The SIEMENS 6DR5023-0NM00-0AA0 SIPART PS2 is a smart, electropneumatic positioner engineered to control valve position with high precision in demanding industrial environments. Designed for linear and part-turn pneumatic actuators, it features non-contacting wear-free position detection (NCS), a robust aluminum enclosure, and a 4…20mA interface.

This double-acting positioner operates without an option module or limit monitor and is provided standard without explosion protection. It includes English, German, and Chinese brief instructions. It ensures reliable depressurization of the actuator during electrical auxiliary power failure (for single-acting only), enhancing plant safety.

Overview

SIPART PS2 positioners from SIEMENS are known for their intelligent control of pneumatic valves based on setpoint signals. They provide advanced diagnostic functions both during live operation and offline phases. The integration of pressure sensors expands its diagnostic capabilities, making it ideal for predictive maintenance strategies.

Design

The SIPART PS2 is built with modular functionality and flexible configuration options:

• Electronics supporting 4–20 mA, HART, PROFIBUS PA, or FOUNDATION Fieldbus (FF)
• Position feedback through potentiometer or NCS (non-contacting sensor)
• Pneumatic block with supply and actuating pressure connections on the enclosure side
• Optional gauge block, booster, venting gauge block, safety solenoid valve, and more
• Available interface for mounting via VDI3847

Optional modules include:

• Analog Output Module (AOM): for analog position feedback
• Digital I/O Module (DIO): with configurable outputs and fault signaling
• Inductive Limit Switches (ILS): dual NAMUR-compliant signal points
• Mechanical Limit Switches (MLS): with integrated fault indicators

The device can also be mounted separately from the actuator in harsh conditions by connecting electrically and pneumatically, ensuring continued operation in areas with high vibration or radiation.

Product Code: 6DR5023-0NM00-0AA0
