6ES7647-8BA42-1NA1 Siemens SIMATIC IPC227E Original Brand New
$2,997.69
6ES7647-8BA42-1NA1
Siemens SIMATIC IPC227E (Nanobox PC); 1x display port; 2x 10/100/1000 Mbit/s Ethernet RJ45; 1 x USB3.0, 3 x USB2.0; CFast slot; 24 V DC industrial power supply Celeron N2807 (2C/2T) 2 GB with NVRAM Box: Basis with COM 1/2 WIN Embedded Standard 7E SP1, English; 32 bit 128 GB CFast; without SIMATIC software DIN rail mounting
[ez-toc]
Overview
SIMATIC IPC227E (Nanobox PC): The Box PC with optimized performance in compact design – maintenance-free and rugged
The SIMATIC IPC227E Nanobox PC is an extremely compact and flexible embedded industrial PC.
Thanks to its closed, dust-protected all-metal enclosure, the IPC227E offers maximum industrial functionality for flexible use under harsh conditions – while remaining maintenance-free.
Modern interfaces and the option for expansion via a PCIe slot mean this Box PC can be easily integrated into the automation system. In the version with pre-installed Industrial Edge Runtime, it also supports modern Edge architectures. In the version with pre-installed Industrial Edge Runtime, it also supports modern Edge architectures. The latest Intel Dual-Core and Quad-Core processors ensure excellent performance here in an ultra-compact design.
Application
The Nanobox PC has a diverse range of applications:
- Control, visualization and communication tasks in areas like mechanical engineering, transportation systems or power transmission
- Acquisition, further processing and visualization of data
- Machine-level applications that additionally require C/C++ programs
- Applications such as shipbuilding, building automation, and storage & logistics
- For Industrial Edge applications for simple, scalable and reliable use of software for data processing (with pre-installed Industrial Edge Runtime):
- Collection, analysis, saving and forwarding of production data
- Installation and scaling of software using container technology
- Central management of devices and software on location or in the cloud
- Full data control from the shop floor to the cloud
Design
Basic design
- All-metal enclosure, resistant to vibrations and shocks, also with high electromagnetic compatibility
- Isolated power supply:
- 24 V DC (19.2 to 28.8 V)
- Graphics connection DisplayPort
- Resolution: Up to 2 560 x 1 600 pixels
- Interfaces (accessible from one side):
- 2 x LAN 10/100/1000 Mbps Ethernet interface (RJ45)
- 1 x USB V3.0, 3 x USB V2.0
- Fieldbus
- PROFINET Realtime via Standard Ethernet interface
Design variants
- Processor/main memory configuration:
- Intel Celeron N2807, 1.58 GHz, Dual Core
- Intel Celeron N2930, 1.83 GHz, Quad Core
- Respectively without/with trusted platform module TPM V2.0
- Main memory configuration
- 2 GB, 4 GB or 8 GB RAM
- Retentive memory
- 512 KB retentive memory (NVRAM), of which 128 KB can be written within the buffer time (optional)
- Serial interface expansion as device variants:
- Without MPI interface
- 2 COM interfaces (RS232 / RS485 / RS422; switchable in the BIOS)
- Hardware expansion as device versions:
- 1 x PCIe slot x1 (optional)
- Drives:
- CFast drive (replaceable, accessible): 8 GB, 16 GB or 128 GB or
- 256 Eco GB solid-state drive, 2.5″ or
- 240 GB solid-state drive, 2.5″ or
- 480 GB solid-state drive, 2.5″ or
- 320 GB hard disk, 2.5″
- Preinstalled operating systems/software:
- Windows Embedded Standard 7 E/P, 32-bit or 64-bit
- Windows 7 Ultimate, multi-language, 32-bit or 64-bit
- Windows 10 IoT Enterprise 2016 LTSB
- Windows 10 IoT Enterprise 2019 LTSC
- Windows 10 IoT Enterprise 2021 LTSC
- Versions with SIMATIC/SINUMERIK Edge
- SIMATIC Industrial OS V2 (Debian-based)
SIMATIC IPC227E (bottom side)
Integrated diagnostics DiagBase
- Integrated, parameterizable monitoring functions (program execution/watchdog, internal enclosure temperature, mass storage)
6ES7647-8BA42-1NA1
Siemens SIMATIC IPC227E (Nanobox PC); 1x display port; 2x 10/100/1000 Mbit/s Ethernet RJ45; 1 x USB3.0, 3 x USB2.0; CFast slot; 24 V DC industrial power supply Celeron N2807 (2C/2T) 2 GB with NVRAM Box: Basis with COM 1/2 WIN Embedded Standard 7E SP1, English; 32 bit 128 GB CFast; without SIMATIC software DIN rail mounting
