6ES7660-8DP01-1BD2 SIEMENS Exclusive SIMATIC IPC547J PCS 7 OS Client Original Brand New

6ES7660-8DP01-1BD2 SIEMENS Exclusive SIMATIC IPC547J PCS 7 OS Client Original Brand New

The SIEMENS 6ES7660-8DP01-1BD2 is an industrial-grade SIMATIC IPC547J rackmount PC designed for SIMATIC PCS 7 OS Client applications. Equipped with a powerful Intel Core i7-10700E processor (8 cores, 16 threads, up to 4.5 GHz), this 4U rack PC offers outstanding performance for control and visualization tasks within industrial automation systems. Preinstalled with PCS 7 V9.1 SP2 and Windows 10 IoT Enterprise 2019 LTSC, it ensures optimal integration into the PCS 7 environment. The system features a 480 GB SSD for fast data access, complemented by 16 GB DDR4 RAM for efficient multitasking and processing.

Overview

6ES7660-8DP01-1BD2 Built for demanding industrial environments, the SIMATIC IPC547J supports continuous 24/7 operation, with a rugged blue-chromated enclosure providing protection against shocks (up to 5 g) and vibrations (up to 0.5 g). Its enhanced connectivity includes three Gbit LAN ports, multiple USB interfaces, and a multi-display setup supporting up to 5 screens via onboard DisplayPorts and a dedicated PCIe graphics card. With seven internal expansion slots (5x PCIe, 2x PCI), this system is ideal for versatile industrial applications requiring scalability, performance, and reliability within the PCS 7 system architecture.

• Intel Core i7-10700E (8 cores/16 threads, 2.9 GHz base, 4.5 GHz turbo, 16 MB cache)
• Preinstalled PCS 7 V9.1 SP2 with Windows 10 IoT Enterprise 2019 LTSC (64-bit)
• 480 GB SSD 2.5″ SATA for internal installation
• 16 GB DDR4 SDRAM (2x 8 GB), Dual Channel
• Temperature and fan monitoring, watchdog, card retainer
• Interfaces: 3x Gbit LAN (RJ45), 1x DVI-D, 2x DisplayPort, 1x COM, Audio
• USB Ports: 6x USB 3.1 Gen2 (rear), 2x USB 3.1 Gen1 (front), 2x USB 2.0 (internal)
• Multi-monitor support: onboard (2x DP) + PCIe graphics card (3x mDP)
• 7 expansion slots: 5x PCIe, 2x PCI
• Industrial 100/240 V AC power supply with USA power cord

Design

• Rugged 19″ 4U rackmount chassis with industrial-grade durability
• Optimized for continuous operation in harsh industrial environments
• Advanced cooling system with comprehensive monitoring functions
• Expandable system for multi-application industrial control setups
• Multi-monitor capability for complex control room applications
• Factory-configured with system recovery and optimized PCS 7 compatibility
