6FC5800-0BP64-0YB0 SIEMENS Exclusive SINUMERIK ONE Run MyScreens Software Option Original Brand New

6FC5800-0BP64-0YB0 SIEMENS Exclusive SINUMERIK ONE Run MyScreens Software Option Original Brand New

The 6FC5800-0BP64-0YB0 SIEMENS software option empowers SINUMERIK ONE users to unlock extended visualization capabilities through Run MyScreens. This electronic license allows users to design and implement custom screen forms directly on the CNC system, offering unmatched flexibility in tailoring machine interfaces to individual operational needs.

With this module, engineers and machine operators can define their own layout, integrate softkeys, display variables, provide interactive help screens, and even launch custom actions upon user input or screen transitions. By supporting dynamic UI elements, mathematical logic, and structured screen hierarchies, the module streamlines complex workflows into intuitive interfaces.

This option is implemented through configurable ASCII files interpreted by an integrated interpreter. These files govern everything from graphics display to variable handling. Examples and templates are included within the toolbox, accelerating development of custom solutions.

Overview

The Run MyScreens function enables custom screen form creation for SINUMERIK ONE (version 6.14 and above). These screen forms enhance control, visualization, and communication between users and machines. Notably:

• Each screen form can include variables, tables, graphics, and logical expressions
• Softkeys can be dynamically reconfigured
• Subprograms and file functions can be integrated for automation

Function

By writing custom screen forms and user cycles, users can:

• Trigger actions via softkeys or variable input
• Update interface layouts in real-time
• Exchange data between screens using PI services

The configuration syntax is straightforward and designed to work seamlessly within CNC environments.

Benefits

• Includes integrated editor for up to 5 screen forms by default
• This option expands capacity beyond 5 screen forms
• Ideal for customized machine interactions and user-friendly extensions

Product Code: 6FC5800-0BP64-0YB0
