6GK5216-4GS00-2TC2 SIEMENS SCALANCE XC216-4C G (E/IP) Exclusive Managed IE Switch Brand New Original
$2,519.22
6GK5216-4GS00-2TC2 Siemens SCALANCE XC216-4C G (E/IP) exclusive managed switch with 12 RJ45, 4 combo ports (RJ45/SFP), full gigabit, IEC 62443-4-2 certified, and EtherNet/IP default.
6GK5216-4GS00-2TC2 SIEMENS SCALANCE XC216-4C G (E/IP) Exclusive Managed IE Switch Brand New Original
SCALANCE XC216-4C G (E/IP) manageable Layer 2 IE switch; IEC 62443-4-2 certified; full gigabit; 12x 10/100/1000 Mbps RJ45 ports; 4x 1000 Mbps combo ports (either 1000 Mbps SFPs or 10/100/1000 Mbps RJ45 ports); 1x console port; diagnostics LED; redundant power supply; temperature range –40 °C to +70 °C; DIN rail/S7/wall mounting; redundancy functions; VLAN, RSTP; PROFINET IO device; default EtherNet/IP; IEEE 1588v2 PTP; C-PLUG slot
Overview
The Siemens SCALANCE XC216-4C G (E/IP) (6GK5216-4GS00-2TC2) is an exclusive full-gigabit managed Layer 2 Industrial Ethernet switch designed for high-performance automation networks with EtherNet/IP as the default protocol. It features 12 RJ45 ports (10/100/1000 Mbps) and 4 combo ports that support either 10/100/1000 Mbps RJ45 or 1000 Mbps SFP transceivers, offering flexible uplink options.
Certified to IEC 62443-4-2 and supporting IEEE 1588v2 Precision Time Protocol (PTP), this model ensures secure, synchronized, and scalable networking. It supports both EtherNet/IP and PROFINET protocols, VLAN segmentation, RSTP, ACLs, IGMP snooping, and IEEE 802.1X authentication. With a rugged enclosure in SIMATIC S7-1500 format, it supports DIN rail, S7-300/S7-1500, or wall mounting.
The XC216-4C G (E/IP) is an exclusive solution for time-critical, secure, and fiber-extendable industrial Ethernet infrastructure.
Key Features
- 12 x 10/100/1000 Mbps RJ45 electrical ports
- 4 x 1000 Mbps combo ports (RJ45 or SFP)
- IEC 62443-4-2 certified; IEEE 1588v2 PTP support
- Default EtherNet/IP protocol; PROFINET switchable
- Redundant 24 V DC power supply via 3-pin terminal block
- Console port (RJ11) and diagnostics LED
- VLAN, RSTP, ACL, IGMP snooping, IEEE 802.1X
- Operating temperature: –40 °C to +70 °C
- DIN rail, SIMATIC S7, or wall mounting
- C-PLUG slot for fast device replacement
Product Code: 6GK5216-4GS00-2TC2
| Weight | 0.52 kg |
|---|---|
| Dimensions | 140 × 125 × 150 mm |
