6GK5334-2TS01-2ER3 SIEMENS SCALANCE XRH334 Exclusive Managed IE Switch Brand New Original

6GK5334-2TS01-2ER3 SIEMENS SCALANCE XRH334 Exclusive Managed IE Switch Brand New Original

SCALANCE XRH334 managed Layer 2 IE switch; 19" rack-mountable; 24x 100/1000 Mbps RJ45 ports; 2x 1G/2.5G/5G/10G RJ45 ports; 8x 1G/10G SFP+ ports; conformal coating; LED diagnostics; error signaling contact; select/set button; PROFINET IO device; network management; integrated redundancy manager; office features (RSTP, VLAN, IGMP); CLP included; 24 V DC power supply

Overview

The Siemens SCALANCE XRH334 (6GK5334-2TS01-2ER3) is an exclusive 19-inch rack-mounted managed Layer 2 Industrial Ethernet switch from the XRH-300 series, designed for high-performance industrial networks with data rates up to 10 Gbps. It features 24 Fast/Gigabit RJ45 ports, 2 multi-rate RJ45 uplinks (up to 10 Gbps), and 8 SFP+ ports for high-speed optical connectivity.

This variant includes conformal coating for enhanced environmental protection and operates on 24 V DC. It runs on the new XRH operating system, enabling future functionalities such as PROFINET over TSN and bumpless redundancy. With LED diagnostics, CLP configuration memory, and rugged IP20 housing, the XRH334 is an exclusive solution for scalable, secure, and resilient industrial automation infrastructure.

Key Features

• 24 x 100/1000 Mbps RJ45 electrical ports
• 2 x 1G/2.5G/5G/10G RJ45 multi-rate uplink ports
• 8 x 1G/10G SFP+ ports for optical uplinks
• IEC 62443-4-2 certified; PROFINET IO and EtherNet/IP compatible
• Conformal coating for harsh environments
• Integrated redundancy manager (MRP, HRP, RSTP, PRP, HSR)
• LED diagnostics and select/set pushbutton
• Console port and signaling contact
• VLAN, IGMP snooping, ACL, IEEE 802.1X
• 24 V DC power supply via 2x 2-pin terminal block
• IP20 metal enclosure; fanless design
• Operating temperature: –40 °C to +60 °C
• 19" rack-mountable; low installation depth

Product Code: 6GK5334-2TS01-2ER3
