6GK5532-2SR00-2RR3 SIEMENS Exclusive SCALANCE XR524-8WG Managed Switch Original Brand New
$11,872.17
6GK5532-2SR00-2RR3 Siemens SCALANCE XR524-8WG Layer 3 managed switch with 24x RJ45, 8x SFP+, 24 V DC, no UL approval.
6GK5532-2SR00-2RR3 SIEMENS Exclusive SCALANCE XR524-8WG Managed Switch Original Brand New
SCALANCE XR524-8WG; managed IE switch, 19″ rack; 24x 10/100/1000 Mbps RJ45 port; 8x 1G/10G SFP+ port; no UL/FM approval; LED diagnostics; select/set button; PROFINET IO device, network management, integrated redundancy manager, office features (RSTP, VLAN, IGMP,…); CPL not included in scope of delivery; power supply 24 V DC; layer 3 integrated.
Overview
The SCALANCE XR-500WG product line (work group switches) are Layer 3 Industrial Ethernet switches for industry-related applications such as control rooms and industry-adjacent environments. They support electrical and optical star, line, and ring topologies with transfer rates of 10/100/1000 Mbps and up to 8x 10 Gbps. Designed for 19″ cabinet installation, these switches ensure high-speed, secure, and redundant network performance.
- 24x RJ45 electrical interfaces (10/100/1000 Mbps)
- 8x SFP+ optical slots (1000/10000 Mbps)
- Redundancy manager supporting Fast/Gigabit Ethernet (MRP, RSTP, MSTP)
- Advanced IT features: VLAN, IGMP Snooping/Querier, QoS, STP variants
- Diagnostics via PROFINET, SNMP, SINEC NMS, CLI, web browser
Design
- Rugged IP20 metal housing, 19″ rack mount
- 24 V DC redundant power input via 2× 2-pin terminal block
- LED status indicators, RESET button, and console port
- Slot for CLP removable storage (not included)
- No UL/FM approval for this variant
Product Code: 6GK5532-2SR00-2RR3
| Weight | 8.2 kg |
|---|---|
| Dimensions | 710 × 510 × 100 mm |
