6GK5534-3TR00-2AR3 SIEMENS Exclusive SCALANCE XR522-12 Managed Switch Original Brand New
$13,747.42
6GK5534-3TR00-2AR3 Siemens SCALANCE XR522-12 Layer 3 managed switch with 34 ports including multigigabit, SFP, and SFP+, power supply 24 V DC, CLP included.
6GK5534-3TR00-2AR3 SIEMENS Exclusive SCALANCE XR522-12 Managed Switch Original Brand New
SCALANCE XR522-12; managed Layer 3 IE switch, 19″ rack; 20x 100/1000 Mbps RJ45 ports; 2x 1G/2.5G/5G/10G RJ45 ports; 4x 100M/1G SFP ports; 8x 1G/10G SFP+ ports; LED diagnostics; error signaling contact; select/set button; PROFINET IO device; network management; integrated redundancy manager; office features (RSTP, VLAN, IGMP,…); CLP included in scope of supply; power supply 24 V DC.
Overview
The SCALANCE XR-500 series delivers industry-grade Layer 3 managed switches for installation in 19″ control cabinets. Designed for fast and redundant communication, these switches support electrical and optical topologies with speeds up to 10 Gbps. With comprehensive IT integration features and powerful diagnostics, the XR522-12 ensures reliable industrial network operations.
- 20x RJ45 ports (100/1000 Mbps)
- 2x multigigabit RJ45 ports (up to 10 Gbps)
- 4x SFP ports (100M/1G)
- 8x SFP+ slots (1G/10G)
- Integrated redundancy manager for high-speed Ethernet ring
- Support for VLAN, IGMP, STP/RSTP/MSTP, QoS, IEEE 802.1X
- PROFINET diagnostics, SNMP, CLI, and SINEC NMS compatibility
Design
- Rugged metal housing, optimized for 19″ rackmount (IP20)
- 24 V DC power input with terminal block
- CLP removable memory included for easy configuration backup
- Status LEDs, fault signal contact, and console port for diagnostics
- Slot for KEY-PLUG expansion (optional Layer 3 enhancement)
Product Code: 6GK5534-3TR00-2AR3
| Weight | 8 kg |
|---|---|
| Dimensions | 710 × 510 × 100 mm |
