6GK6498-0RB00-1AN1 SIEMENS Exclusive RUGGEDCOM RSG909R Managed HSR/PRP Ethernet Switch Conformal Coated Original Brand New

6GK6498-0RB00-1AN1 SIEMENS Exclusive RUGGEDCOM RSG909R Managed HSR/PRP Ethernet Switch Conformal Coated Original Brand New

For price details, please contact our customer service

The SIEMENS 6GK6498-0RB00-1AN1 RUGGEDCOM RSG909R is a 9-port industrial-grade managed Ethernet switch with integrated HSR/PRP RedBox, specifically designed for high-demand applications in critical industrial environments. With conformal coating for enhanced protection against moisture, dust, and corrosive agents, this model provides reliable network redundancy through HSR and PRP as per IEC 62439-3, making it ideal for energy, transportation, and oil & gas sectors. Equipped with 6x 10/100/1000BASE-TX RJ45 ports and 3x 1G SFP slots, it delivers flexible connectivity and assured uptime even under harsh conditions from -40°C to +85°C.

Overview

As part of the RUGGEDCOM RSG900R family, the RSG909R with conformal coating combines advanced Ethernet switching with integrated HSR/PRP RedBox in a compact DIN-rail mountable unit. The IEEE 1588 support ensures high-precision time synchronization, vital for applications requiring real-time communication. Siemens ROS™ (Rugged Operating System) embedded in this switch enhances cybersecurity and network performance. Designed for reliable operation in mission-critical infrastructures, it comes with universal power supply options and industrial certifications including IEC 61850-3, IEEE 1613, and IEC Ex.

• 9-port managed industrial Ethernet switch with HSR/PRP RedBox and conformal coating
• 6x 10/100/1000BASE-TX RJ45 copper ports
• 3x 1G SFP slots for flexible uplink options
• Precision time synchronization with IEEE 1588 support
• Operating temperature from -40°C to +85°C (fanless)
• DIN-rail mountable with compact design
• Redundant power inputs for maximum reliability
• Rugged Operating System (ROS™) with comprehensive cybersecurity features

Design

• Compact industrial-grade construction with front-facing ports
• HSR/PRP RedBox integrated for seamless redundancy
• Universal low-voltage DC dual inputs (10 – 60 V DC)
• Universal high-voltage dual inputs (100 – 240 V AC / 100 – 300 V DC)
• Conformal coated PCB for additional environmental protection
• Meets IEC 61850-3, IEEE 1613, and IEC Ex standards
