6GK7243-8RX30-0XE0 SIEMENS Exclusive CP 1243-8 IRC Communications Processor Original Brand New
$868.40
SIEMENS CP 1243-8 IRC processor for S7-1200, supports SINAUT ST7, DNP3, IEC 60870-5 with WAN redundancy.
6GK7243-8RX30-0XE0 SIEMENS Exclusive CP 1243-8 IRC Communications Processor Original Brand New
The SIEMENS 6GK7243-8RX30-0XE0 is the CP 1243-8 IRC communications processor designed to enable remote communication capabilities for SIMATIC S7-1200 PLCs within TeleControl Professional systems. Supporting protocols such as SINAUT ST7, DNP3, and IEC 60870-5-104, this module provides industrial-grade WAN connectivity for control centers, especially in energy, utility, and infrastructure applications.
Overview
This communication processor allows connection of the S7-1200 as a Remote Terminal Unit (RTU) to a higher-level control system or ST7 control center. Equipped with two WAN interface options—via Ethernet and optional TS modules (RS232, MODEM, ISDN, or GSM)—it supports route redundancy and offers reliable, secure communication over public or private networks. With built-in IPsec VPN, Stateful Inspection Firewall, and compatibility with SINEMA Remote Connect, it ensures secure and configurable remote connectivity. Time synchronization, email/text alarms, and buffering of up to 16,000 data frames further support telecontrol reliability and flexibility in the field.
- Supports SINAUT ST7, DNP3, IEC 60870-5-104 telecontrol protocols
- Two WAN interfaces for redundant path communication
- Integrated RJ45 Ethernet port for router connection
- Expandable via TS modules: RS232, MODEM, ISDN, GSM
- VPN security with IPsec encryption and firewall
- Autoconfiguration via SINEMA Remote Connect
- Data buffering up to 16,000 frames
- Email and SMS alarm notifications
- Web diagnostics and STEP 7 configuration
- NTP-based time synchronization
Design
- Compact S7-1200 format with rugged plastic housing
- DIN rail mountable with front-access terminals and diagnostics
- 3-pin terminal for 24 V DC power supply
- CP plugs to the left of the CPU; TS module plugs left of the CP
- Easy replacement and modular expandability
Product Link: 6GK7243-8RX30-0XE0
| Weight | 0.187 kg |
|---|---|
| Dimensions | 25 × 210 × 290 mm |
