6GK8781-1WD02-0AK2 SIEMENS Exclusive SINEC NMS Configuration XL 3Y Temporary License Original Brand New

6GK8781-1WD02-0AK2 SIEMENS Exclusive SINEC NMS Configuration XL 3Y Temporary License Original Brand New

The SIEMENS 6GK8781-1WD02-0AK2 is a temporary license for SINEC NMS Configuration XL with a 36-month runtime and no automatic extension. This license enables comprehensive configuration management for up to 10,000 IP devices in demanding industrial network environments. Delivered via OSD, it requires a valid SINEC NMS Monitoring XL license for operation and supports large-scale infrastructure with advanced diagnostics and monitoring capabilities.

Overview

SINEC NMS is Siemens’ high-performance network management system for centralized monitoring and administration of industrial networks. It supports networks with tens of thousands of nodes, combining SNMP, SIMATIC, and PROFINET diagnostics within a single platform. The system’s distributed architecture allows flexible expansion while storing data in a long-term archive for analysis. Seamless integration with HMI/SCADA systems (such as WinCC and PCS 7) is achieved via OPC UA, REST API, and web interfaces, including compatibility with ticketing systems like ServiceNow. The Configuration module further enhances functionality by allowing structured configuration management and device configuration backup to safeguard system integrity.

• 36-month temporary license for SINEC NMS Configuration XL
• Supports configuration of up to 10,000 IP devices
• Delivered via Online Software Delivery (OSD)
• Requires active Monitoring XL license
• Unified diagnostics through SNMP, SIMATIC, and PROFINET
• HMI/SCADA integration via OPC UA, REST API, and web interfaces
• REST API support for service platforms like ServiceNow
• Centralized configuration management with rule-based approach
• Firmware update management across the entire network infrastructure

Design

• Two-tier architecture with Control and Operation layers
• Control acts as central management for distributing devices to Operations
• Up to 75 Operations per Control supported
• Each Operation manages up to 500 devices without additional licensing
• Comprehensive features including fault, performance, security, and configuration management
• Advanced firewall and certificate administration capabilities
• Northbound interface for integration with higher-level systems
• Long-term data storage and detailed reporting functions
• Scalable design suitable for extensive industrial applications
