7MF0300-1NE01-5AF2-ZA00E00H01Y01 SIEMENS Exclusive SITRANS P320 Pressure Transmitter Original Brand New

7MF0300-1NE01-5AF2-ZA00E00H01Y01 SIEMENS Exclusive SITRANS P320 Pressure Transmitter Original Brand New

The SIEMENS SITRANS P320 with product code 7MF0300-1NE01-5AF2-ZA00E00H01Y01 is a state-of-the-art gauge pressure transmitter designed to deliver precise and reliable pressure measurement in industrial environments. Built with advanced HART communication (4–20 mA), this device ensures seamless integration into existing control systems and allows for efficient monitoring and configuration. Its robust design and stainless-steel construction make it an ideal solution for demanding applications where long-term durability and consistent performance are essential.

This model is equipped with a silicone oil-filled measuring cell and a maximum measuring span of 4000 mbar (58 psi). The process connection features a 1/2-14 NPT female thread with high-grade stainless steel 316L/1.4404 to guarantee resistance against corrosion and harsh operating conditions. The sensor differential pressure is supported by a stainless-steel process flange, while the die-cast aluminum housing provides durability and protection. A dual-chamber design with a glass window display ensures operators can easily read measurement values on-site.

Overview

The SITRANS P320 series is designed for global applicability, carrying general approval for use worldwide, including CE, UKCA, and RCM certifications. It excludes CSA, EAC, FM, and KC, making it suitable for most international installations. Cable glands and sealing plugs are pre-installed for convenience, and the unit comes with an electrogalvanized steel mounting bracket for straightforward installation.

Design Features

The intelligent design of the transmitter allows for easy configuration of measurement ranges. Users can set both lower and upper range values, define units such as mbar, bar, kPa, MPa, or psi, and benefit from flexible adjustments to meet different industrial requirements. The integrated display provides clear visualization of readings, while the housing protects the sensitive electronics from dust, moisture, and mechanical stress. This combination of mechanical strength and digital functionality makes the SITRANS P320 a trusted choice across multiple industries, from process automation to heavy manufacturing.

Product Code: 7MF0300-1NE01-5AF2-ZA00E00H01Y01
