7MF1565-3CB00-1AA1 SIEMENS Exclusive SITRANS P200 Pressure Transmitter Original Brand New

7MF1565-3CB00-1AA1 SIEMENS Exclusive SITRANS P200 Pressure Transmitter Original Brand New

The SIEMENS 7MF1565-3CB00-1AA1 SITRANS P200 is a high-quality pressure transmitter designed to deliver precise and reliable measurements in a wide range of industrial applications. Engineered with a robust ceramic measuring cell and housed in durable stainless steel, this device offers superior performance when measuring both gauge and absolute pressure in liquids, gases, and vapors. With a typical non-linearity of only 0.25 percent, the transmitter ensures excellent accuracy and consistency even under demanding operating conditions.

This transmitter features a measuring range up to 16 bar with overload protection up to 40 bar, making it suitable for general industrial processes that require dependable monitoring. The output signal of 4 to 20 mA via two-wire technology ensures easy integration with existing systems, while the power supply requirement of 7 to 33 V DC offers installation flexibility. Its electrical connection follows EN 175301-803-A standards, with threaded gland M16 options for convenient and secure wiring. The process connection is standardized with G1/2″ male threads to EN 837-1, which allows compatibility with a wide range of setups. Viton (FPM) sealing material ensures reliable durability against challenging media.

Overview

The SITRANS P200 transmitter series is built for general-purpose applications requiring reliable pressure monitoring. Featuring both gauge and absolute measuring ranges from 1 to 60 bar (15 to 1000 psi), the transmitter is highly versatile across industries. The ceramic measuring cell ensures long-term stability, while the rugged design provides resilience in harsh environments.

Design

The transmitter is available in two structural variants. The standard version without explosion protection integrates a piezoresistive measuring cell within a stainless steel enclosure. It supports multiple electrical connection options, including EN 175301-803-A plugs (IP65), M12 plugs (IP67), cable connections (IP67), and Quickon quick screw connections (IP67). The flexible output includes 4 to 20 mA, 0 to 10 V, or IO-Link signals depending on configuration. For environments requiring explosion protection, the unit provides the same durable enclosure and measuring technology but adheres to stricter standards, offering safe operation while maintaining accuracy.

Product Code: 7MF1565-3CB00-1AA1
