7ML5050-0AA22-1DA0 SIEMENS Exclusive SITRANS LUT420 Ultrasonic Level Controller Original Brand New

7ML5050-0AA22-1DA0 SIEMENS Exclusive SITRANS LUT420 Ultrasonic Level Controller Original Brand New

The 7ML5050-0AA22-1DA0 is part of the advanced SITRANS LUT400 series, a high-performance ultrasonic level controller engineered for precise and reliable measurement in a wide variety of industrial applications. Designed for continuous, non-contact monitoring, it offers an impressive measuring range of up to 60 meters (197 feet), making it ideal for tanks, silos, and open channels. Its capability to accurately monitor level, volume, and volume flow in liquids, slurries, and bulk solids ensures optimal process efficiency.

This model, the SITRANS LUT420, is equipped with a user-friendly display, a robust enclosure, and multiple input and output options, including HART communication, two discrete inputs, three relays, and a single mA output. With support for one external temperature sensor input and one transducer input, the unit delivers exceptional measurement precision even under challenging environmental conditions. The integrated data logging functionality allows for detailed process tracking, supporting both operational control and regulatory compliance.

The unit is designed for an input voltage range of 10 to 32 V DC and comes with three cable inlets and M20 plastic cable glands for easy installation. Its approvals for Ordinary Locations, CE, UKCA, FM, CCSAUS, UL, RCM, EAC, and KC ensure compliance with international safety and performance standards. The SITRANS LUT420 is a versatile and dependable choice for industries requiring high-accuracy, non-invasive level measurement solutions.

Overview

Engineered to provide consistent and repeatable measurements, the SITRANS LUT420 offers a cost-effective solution for level and flow monitoring without direct contact with the measured material. Its ultrasonic technology eliminates the need for maintenance-prone mechanical components, reducing downtime and operational costs.

Product Code: 7ML5050-0AA22-1DA0
