1FL6052-2AF21-2AB1

Description

Overview

The Siemens SIMOTICS S-1FL6052-2AF21-2AB1 is a high-performance servo motor designed for precision industrial applications. With a power rating of 1.5 kW and operating voltage of 230 V 3AC, it delivers reliable performance at speeds up to 3000 rpm. The motor includes a TTL incremental encoder with 2500 pulses per revolution for accurate motion control. Its 50 mm shaft with feather key ensures easy integration, and the integrated holding brake provides additional safety and operational stability. Designed for use with SINAMICS V90 converters, this motor combines efficiency, precision, and durability.

Benefit

• Plug-and-Play Integration: Optimized specifically for use with SINAMICS V90 servo drives.

• Enhanced Safety: Equipped with an integrated holding brake to maintain position during power-off states.

• High Precision: The TTL incremental encoder (2500 pulses per revolution) delivers exacting feedback for smooth operation.

• Durable Design: Features an IP65 degree of protection with an oil sealing ring to withstand harsh industrial conditions.

Function & Features

• Operating Voltage: 230 V 3AC

• Power Rating: 1.5 kW

• Nominal Speed: 3000 rpm

• Torque: M0 = MN = 4.78 Nm

• Shaft: 50 mm with feather key

• Encoder: Incremental TTL, 2500 pulses per revolution

• Holding Brake: Integrated for reliable stopping and safety

• Protection: Sealing ring for durability

• Compatibility: SINAMICS V90 converters
