Siemens 3RT1064-6XB46-0LA2 Power Contactor 225A, 110kW, 24V DC, PLC Compatible Original Brand New

Overview

The Siemens 3RT1064-6XB46-0LA2 is a high-performance power contactor designed for demanding industrial applications. With a robust rating of 225 A for AC-3e/AC-3 operation and a power rating of 110 kW at 400 V, this 3-pole contactor is engineered for reliable switching of motors and other high-current loads. Its versatile design features an electronic drive with a 24 V DC control voltage range (Uc​:24 V DC ×(0.7−1.25)), and is equipped with a PLC input for 24-110 V DC, making it highly compatible with modern automation systems.

The inclusion of two normally open (2 NO) and two normally closed (2 NC) auxiliary contacts provides flexibility for control and signaling circuits. This model is specifically designed to meet the extended rated conditions for railroad applications according to IEC 60077, ensuring exceptional durability and performance in harsh environments. The main circuit connection is via busbars, while the control and auxiliary circuits use convenient screw terminals for easy installation.

Benefit

• High Performance & Reliability: With a 225 A rating and 110 kW power capacity, this contactor ensures reliable switching of heavy-duty loads.
• PLC Integration: The wide-range PLC input ($24-110\text{ V DC}$) simplifies integration into existing automation and control systems.
• Enhanced Durability: Built to meet IEC 60077 standards for railroad applications, this contactor offers extended durability and operational reliability in challenging environments.
• Flexible Control: The electronic drive with a wide control voltage range ($24\text{ V DC }\times (0.7-1.25)$) allows for stable operation even with voltage fluctuations.
• Comprehensive Auxiliary Contacts: The 2 NO + 2 NC auxiliary contacts provide ample flexibility for control and signaling circuits, reducing the need for additional components.
• Easy Installation: Busbar connections for the main circuit and screw terminals for control/auxiliary circuits streamline the installation and maintenance process.

Function

• Motor Control: Designed for the switching of 3-phase AC motors.
• Load Switching: Suitable for general-purpose high-current load switching applications.
• Automation Interface: The PLC input allows for direct control from programmable logic controllers.
• Railroad Applications: Specifically engineered to perform reliably under the demanding extended rated conditions of railroad systems, as per IEC 60077.
• Safety & Signaling: The auxiliary contacts can be used for interlocking, status feedback, and other control functions.

Technical Specification

• Product Name: Siemens 3RT1064-6XB46-0LA2
• Type: Power Contactor
• Rated Current (AC-3e/AC-3): 225 A
• Rated Power (400 V): 110 kW
• Number of Poles: 3
• Control Voltage (Uc​): 24 V DC, operating range 0.7−1.25×Uc​
• PLC Input: 24-110 V DC
• Auxiliary Contacts: 2 NO + 2 NC
• Drive: Electronic
• Main Circuit Connection: Busbar
• Control & Auxiliary Circuit Connection: Screw Terminal
• Compliance: IEC 60077 (extended rated condition railroad)
