Siemens 3RT1364-6AF36 Contactor 350A, 400V, 4-Pole, AC-1 Wide-Range 48-130V AC/DC Control Rail/Screw Terminal Original Brand New

Overview

The Siemens 3RT1364-6AF36 is a robust and reliable 4-pole contactor from the S10 frame size, specifically designed for switching non-inductive or weakly inductive loads (AC-1) up to 350 A at 400 V and 40 °C. This high-performance contactor features a versatile wide-range solid-state operating mechanism, accepting control voltages from 48 V to 130 V AC/DC, making it highly adaptable for various industrial applications. Equipped with a 2 NO + 2 NC auxiliary contact configuration and flexible connection options (connecting rail/screw terminal), the 3RT1364-6AF36 ensures efficient and secure power control in diverse settings. Built to IEC 60947 standards, it offers exceptional reliability and performance for critical power switching tasks, including load disconnection, power generation plant integration, and transfer switching.

Function

• 4-Pole AC-1 Switching: Capable of switching four circuits simultaneously for non-inductive or weakly inductive loads, ideal for resistive heating, distribution circuits, and isolation.
• High Current Capacity: Handles up to 350 A at 400 V AC, suitable for demanding power applications.
• Wide-Range AC/DC Control: Flexible control voltage input from 48 V to 130 V AC/DC simplifies integration into various control systems.
• Integrated Auxiliary Contacts: Features 2 normally open (NO) and 2 normally closed (NC) auxiliary contacts for signaling and interlocking functions.
• Coil Damping (Varistor): Built-in varistor for effective damping of opening surges in the coil, protecting control circuits and extending contactor life.
• Flexible Connection: Offers both connecting rail and screw terminal options for main circuit connections, providing installation versatility.
• Electromagnetic Compatibility (EMC): Fulfills requirements for environment category A, ensuring reliable operation in industrial environments.

Benefit

• Exceptional Reliability: Manufactured to IEC 60947 standards, ensuring consistent and safe operation in demanding industrial environments.
• Versatile Application: Ideal for a wide range of AC-1 applications, including load disconnection, power generation plant switching, and transfer switching.
• Reduced Inventory: Wide-range control voltage minimizes the need for different coil variants, simplifying stock management.
• Enhanced Circuit Protection: Integrated coil damping protects the control circuit from voltage spikes, improving system longevity.
• Easy Integration: Clear connection options and adherence to international standards facilitate seamless integration into existing and new electrical systems.
• High Contact Reliability: Auxiliary contacts are designed for high contact reliability, even at low voltages and currents, suitable for solid-state circuits.
• Robust Design: S10 frame size provides a sturdy and durable solution for heavy-duty applications.

Protection and Safety:

The Siemens 3RT1364-6AF36 contactor requires appropriate short-circuit, overload, and overvoltage protection for all connections. Refer to the technical product data sheet and configuration manuals for detailed guidance on protecting main, auxiliary, and control supply voltage connections. Integrated varistor damping for the coil helps mitigate opening surges, but the influence on break and delay times should be considered.

Connection Methods:

• Main Circuit: Screw terminals with connecting bars, allowing connection via cable lugs or flexible/rigid busbars. Can be fitted with broadened bus connectors.
• Auxiliary and Control Circuit: Screw terminals.

Compatibility and Accessories:

For overload protection, the 3RT1364-6AF36 is compatible with 3RB2 electronic overload relays. While the operating mechanism and contacts are not replaceable for this model, a wide range of accessories for 3RT135 to 3RT137 contactors are available to expand functionality, including additional auxiliary switches.
