Siemens 3RT2325-1AF00 SIRIUS Contactor, AC-1, 35A, 4-Pole, 110V AC Coil, Screw Terminal, Size S0 Original Brand New

Siemens 3RT2325-1AF00 SIRIUS Power Contactor for AC-1 Application

The Siemens 3RT2325-1AF00 is a robust and reliable 4-pole SIRIUS power contactor designed for demanding AC-1 applications, such as switching weak or non-inductive loads. With a rated current of 35 A at 400 V and 40 °C, this compact Size S0 contactor offers exceptional performance and longevity for industrial control systems.

Overview

Part of the renowned Siemens SIRIUS modular system, the 3RT2325-1AF00 contactor is built to meet global industrial standards, including IEC 60947-1, IEC 60947-4-1, and IEC 60947-5-1. It features a 110 V AC, 50 Hz operating mechanism and comes equipped with 1 normally open (NO) and 1 normally closed (NC) integrated auxiliary contacts for flexible control circuit integration. The convenient screw terminals ensure secure and straightforward wiring.

Key Features & Function

• AC-1 Application Specific: Optimized for switching non-inductive or weakly inductive loads, making it ideal for heating, lighting, or resistive load circuits.
• 4-Pole Design: Provides versatile switching capabilities for various three-phase and single-phase applications.
• High Current Rating: Handles up to 35 A at 400 V / 40 °C, ensuring reliable operation in demanding environments.
• 110 V AC Coil: Standard 110V AC, 50 Hz coil for common industrial control voltages.
• Integrated Auxiliary Contacts (1 NO + 1 NC): Enhances control circuit flexibility, enabling feedback, interlocking, and status indication.
• Screw Terminals: Provides robust and easy-to-use connections for main, auxiliary, and control circuits.
• Compact Size S0: Space-saving design for efficient panel layout.
• Standards Compliant: Meets international standards IEC 60947-1, IEC 60947-4-1, and IEC 60947-5-1, guaranteeing quality and safety.
• Electromagnetic Compatibility (EMC): Fulfills requirements for environment category A, suitable for industrial settings.
• Contact Reliability: Auxiliary contacts are designed for high contact reliability, even at low voltages (≤ 110 V) and currents (≤ 100 mA), making them suitable for solid-state circuits.

Benefit

• Reliable Performance: Siemens’ proven engineering ensures consistent and long-lasting operation in critical industrial applications.
• Enhanced Safety: Designed with considerations for short-circuit, overload, and overvoltage protection, contributing to a safer electrical system.
• Flexible Integration: Modular design and integrated auxiliary contacts allow for easy integration into complex control circuits and motor feeder combinations.
• Ease of Installation: Screw terminals simplify wiring, reducing installation time and effort.
• Versatile Application: Ideal for a wide range of AC-1 switching tasks, from disconnecting loads to transfer switching.
• Expandable System: Compatible with various SIRIUS accessories such as overload relays (3RU2, 3RB3), surge suppressors, and additional auxiliary switches, allowing for customized solutions.
• Global Recognition: Siemens is a trusted brand, ensuring product availability and support worldwide.

Protection and Connection:

The 3RT2325-1AF00 emphasizes comprehensive protection. All connections (main, auxiliary, control) must be safeguarded against overload and short circuits. For detailed guidance on protection for free-standing contactors or device combinations (e.g., with overload relays or circuit breakers), refer to Siemens’ technical product data sheets and configuration manuals. Overvoltage protection for the control supply voltage can be achieved by retrofitting with optional surge suppressors (RC elements, varistors, diodes), which are available as accessories.

Connection Methods:

• Main Circuit: Screw terminals are provided for secure main power connections.
• Auxiliary and Control Circuit: Screw terminals ensure reliable connections for auxiliary and control wiring.

Motor Protection:

While primarily for AC-1 applications, the 3RT2325-1AF00 can be combined with Siemens 3RU2 thermal overload relays or 3RB3 electronic overload relays for robust motor protection against overload.

Operating Mechanism:

This contactor features a conventional AC operating mechanism, controlled via the A1-A2 terminals with a 110 V AC, 50 Hz supply. The solenoid coil is replaceable, extending the lifespan of the unit.

Accessories and Spare Parts:

Expand the functionality of your 3RT2325-1AF00 with a wide range of SIRIUS accessories, including additional auxiliary switches, surge suppressors, and various spare parts. Consult the Siemens Accessories and Spare Parts for SIRIUS 3RT2 contactors catalog for a complete list.

Application

The Siemens 3RT2325-1AF00 contactor is ideally suited for:

• Four-pole switching of weak or non-inductive loads (AC-1)
• Disconnecting loads or power generation plants from the grid
• Transfer switching applications

For specialized applications involving motor-driven loads (AC-3), Siemens also offers specific versions of 3RT23 contactors.

Purchase the Siemens 3RT2325-1AF00 today at Turll and optimize your industrial control systems for reliability and performance.
