Siemens 3SU1051-6AA60-0AA0 Round Metal, White, Indicator Light, 22mm Original Brand New
$3.85
A premium 22mm round indicator light from the Sirius Act series. Featuring a sleek, shiny metal bezel and a smooth white lens, it provides clear visual signaling for industrial control panels and machinery.
Availability: In stock
Overview
The Siemens 3SU1051-6AA60-0AA0 is a premium indicator light from the SIRIUS ACT series. Designed for industrial applications requiring high durability and aesthetic appeal, this 22mm pilot light features a sleek, shiny metal bezel and a smooth white lens. Whether you are upgrading a control panel or building a new automation system, this component offers the rugged reliability Siemens is known for.
Benefit
-
Extreme Durability: The shiny metal construction provides superior mechanical resistance compared to plastic alternatives.
-
Modern Design: Part of the award-winning SIRIUS ACT line, offering a sleek look for high-end control panels.
-
Easy Installation: Designed for simple, one-handed installation without the need for specialized tools.
-
Clear Visibility: The smooth white lens ensures high-contrast signaling for status indication.
Function
- Mounting Diameter: Standard 22mm round cutout.
- Material: High-quality metal, shiny finish for corrosion resistance.
- Lens Style: Smooth, flat lens for easy cleaning and wide-angle visibility.
- Modular System: Compatible with various SIRIUS ACT contact blocks and LED modules (sold separately).
- Environmental Protection: High IP rating suitable for harsh industrial environments.
Visit 3SU1051-6AA60-0AA0 for more detail info
For more our products visit turll
Download
| Weight | 0.025 kg |
|---|---|
| Dimensions | 30.00 × 45.00 × 30.00 mm |
| Brand | SIEMENS |
| product brand name | SIRIUS ACT |
| product designation | Indicator lights |
| design of the product | Actuating/signaling element |
| product type designation | 3SU1 |
| product line | Metal, shiny, 22 mm |
| product extension optional | – |
| ● light source | Yes |
| ● contact module | No |
| color | – |
| ● of the actuating element | white |
| material of the actuating element | plastic |
| shape of the actuating element | round |
| outer diameter of the actuating element | 29.45 mm |
| product component front ring | No |
| protection class IP | IP66, IP67, IP69(IP69K) |
| degree of protection NEMA rating | 1, 2, 3, 3R, 4, 4X, 12, 13 |
| shock resistance | – |
| ● acc. to IEC 60068-2-27 | Sinusoidal half-wave 50g / 11 ms |
| vibration resistance | – |
| ● acc. to IEC 60068-2-6 | 10 … 500 Hz: 5g |
| reference code acc. to IEC 81346-2 | P |
| tightening torque of the screws in the bracket | 1 … 1.2 N·m |
| ambient temperature | – |
| ● during operation | -25 … +70 °C |
| ● during storage | -40 … +80 °C |
| environmental category during operation acc. to IEC 60721 | 3M6, 3S2, 3B2, 3C3, 3K6 (with relative air humidity of 10 … 95 %) |
| shape of the installation opening | round |
| mounting diameter | 22.3 mm |
| positive tolerance of installation diameter | 0.4 mm |
| mounting height | 11.8 mm |
| installation width | 29.5 mm |
| installation depth | 24.4 mm |
| last modified: | 10/6/2021 |
