Siemens 3SU1401-1BB60-1AA0 LED Module, 24V AC/DC, White, Screw Terminal Original Brand New

Model / SKU3SU1401-1BB60-1AA0

High-performance LED module from the SIRIUS ACT series. It features an integrated white LED designed for 24V AC/DC operation with secure screw terminal connections. Optimized for front plate mounting in industrial control panels.

Original price was: $7.32.Current price is: $3.39.
In stockShips in 1–3 business days
  • ConditionOriginal Brand New
  • Warranty12 months
Request bulk quoteAsk on WhatsApp
  • Genuine Products
  • Up to 1-Year Warranty
  • Global Shipping
  • Secure Payment
  • PI / Bank Transfer Available
  • Bulk Quote Support

Description

Overview

The Siemens 3SU1401-1BB60-1AA0 LED module is a reliable, energy-efficient solution designed for industrial and commercial applications. Featuring a bright white LED integrated into a compact module, it supports 24 V AC/DC operation and ensures easy installation with screw terminals for secure front plate mounting. Perfect for control panels, signaling, and machinery indicators, this LED module combines durability with excellent visibility.

Key Benefit

  • Superior Visibility: Integrated high-intensity white LED provides clear status indication even in high-light environments.

  • Versatile Power: Compatible with both 24V AC and 24V DC systems, reducing inventory complexity.

  • Fast Installation: Designed for front plate mounting with a reliable screw terminal system for secure wiring.

  • Industrial Durability: Built to the rigorous standards of the Siemens SIRIUS ACT line, ensuring resistance to vibration and long service life.

Function

  • Indicator for control panels and machinery

  • Status signaling in industrial environments

  • Easy integration into modular front plates

  • Reliable operation in AC/DC circuits

Application

This LED module is ideal for use in:

  • Industrial Control Panels

  • Machine Status Indicators

  • Automation Systems

  • Emergency Stop Signalization

Download

Datasheet in PDF

Visit 3SU1401-1BB60-1AA0 for more detail info

For more our products visit turll



Specifications

SKU / Model3SU1401-1BB60-1AA0
BrandSIEMENS
product brand nameSIRIUS ACT
product designationLED module
product type designation3SU1
product component-
● diodeYes
● lamp transformerNo
● light sourceYes
● series resistorNo
insulation voltage rated value320 V
degree of pollution3
type of voltage of the operating voltageAC/DC
● for actuationAC/DC
surge voltage resistance rated value4 kV
consumed current maximum25 mA
protection class IP-
● of the enclosureIP40
● of the terminalIP20
shock resistance-
● acc. to IEC 60068-2-27Sinusoidal half-wave 50g / 11 ms
vibration resistance-
● acc. to IEC 60068-2-610 ... 500 Hz: 5g
● for railway applications acc. to DIN EN 61373Category 1, Class B
operating period typical100 000 h
reference code acc. to IEC 81346-2P
operating voltage 1-
● at AC-
— at 50 Hz rated value24 V
— at 60 Hz rated value24 V
● at DC rated value24 V
relative positive tolerance of the operating voltage20 %
relative negative tolerance of the operating voltage20 %
inrush current maximum2 A
type of electrical connectionscrew-type terminals
type of connectable conductor cross-sections-
● solid with core end processing2x (0.5 ... 0.75 mm²)
● solid without core end processing2x (1.0 ... 1.5 mm²)
● finely stranded with core end processing2x (0.5 ... 1.5 mm²)
● finely stranded without core end processing2x (1,0 ... 1,5 mm²)
● at AWG cables2x (18 ... 14)
tightening torque with screw-type terminals0.8 ... 0.9 N·m
type of light sourceLED
color of the light sourcewhite
light intensity900 ... 1 400 mcd
certificate of suitability-
● ATEXNo
● IECExNo
ambient temperature-
● during operation-25 ... +70 °C
● during storage-40 ... +80 °C
environmental category during operation acc. to IEC 607213M6, 3S2, 3B2, 3C3, 3K6 (with relative air humidity of 10 ... 95 %, no condensation in operation permitted)
fastening method-
● of modules and accessoriesFront plate mounting
last modified:10/6/2021
Weight0.009 kg
Dimensions30.00 × 30.00 × 10.00 mm
