Siemens 3SU1852-0AA00-0AB1 Metal Enclosure for 22 mm Command Devices, 2 Control Points Original Brand New
$34.32
Durable metal enclosure for 22 mm command devices with 2 control points, label recess, floor mounting, and dual M20 cable entries (top and bottom). Ideal for industrial applications.
Availability: In stock
Overview
The Siemens 3SU1852-0AA00-0AB1 is a high-quality, durable metal enclosure designed for 22 mm command and signaling devices. Engineered for industrial reliability, this enclosure offers a round design with a gray metal top part, providing long-lasting protection in demanding environments. It features two control points, allowing flexible configuration for pushbuttons, switches, or indicators.
Designed with convenience and safety in mind, the enclosure includes a label recess for clear identification, as well as 1× M20 cable entry on both the top and bottom, making installation efficient and adaptable. Ideal for control panels, machinery, industrial automation systems, and building technology applications.
Benefit
-
Strong metal construction ensures long service life in harsh industrial conditions.
-
Two control points allow customization with various command devices.
-
Efficient installation via M20 openings on both top and bottom.
-
Clear labeling space for improved operational safety.
-
Compact, round 22 mm design suitable for space-restricted control panels.
-
Siemens quality guarantees reliability, compatibility, and superior engineering.
Features & Functions
-
Enclosure type: Round enclosure for 22 mm command devices
-
Material: High-strength metal
-
Color: Gray top part
-
Control points: 2 (empty, without command equipment)
-
Mounting method: Floor mounting
-
Cable entries: 1× M20 top, 1× M20 bottom
-
Label recess: Yes, for easy identification
-
Application areas: Industrial automation, machine control, panel building, signaling equipment
Visit 3SU1852-0AA00-0AB1 for more detail info
For more our products visit turll
Download
| Weight | 0.570 kg |
|---|---|
| Dimensions | 100.00 × 110.00 × 80.00 mm |
| Brand | SIEMENS |
| product brand name | SIRIUS ACT |
| product designation | Enclosures |
| product type designation | 3SU1 |
| design of the housing | with recess for label |
| shape of the enclosure front | rectangular |
| material of the enclosure | metal |
| number of command points | 2 |
| product component protective collar | No |
| color of the enclosure top part | grey |
| fastening method of the enclosure | Vertical / horizontal |
| protection class IP | IP66, IP67, IP69(IP69K) |
| degree of protection NEMA rating | 1, 2, 3, 3R, 4, 4X, 12, 13 |
| shock resistance for railway applications acc. to DIN EN 61373 | Category 1, Class B |
| vibration resistance for railway applications acc. to DIN EN 61373 | Category 1, Class B |
| cable entry type | Without |
| type of electrical connection on enclosure | Cable routing above and below, both 1 x M20 |
| tightening torque of fixing screws in the enclosure cover | 1.5 … 1.7 N·m |
| ambient temperature | – |
| ● during operation | -25 … +70 °C |
| ● during storage | -40 … +80 °C |
| environmental category during operation acc. to IEC 60721 | 3M6, 3S2, 3B2, 3C3, 3K6 (with relative air humidity of 10 … 95 %, no condensation in operation permitted for all devices behind front panel) |
| fastening method of modules and accessories | Floor mounting |
| mounting diameter | 22.3 mm |
| positive tolerance of installation diameter | 0.4 mm |
| last modified: | 12/21/2020 |
