Siemens 3TB4022-0XG1 Contactor AC 60Hz, 110V, 9A, 4kW, 1NO+1NC Auxiliary, Screw Terminal Original Brand New

Overview

The Siemens 3TB4022-0XG1 is a high-performance AC contactor designed for reliable switching of electrical loads. Engineered for durability and efficiency, this contactor is ideal for a wide range of industrial and commercial applications, including motor control, lighting, and heating systems. With a robust design and precise specifications, it ensures safe and effective operation in demanding environments. This contactor is part of the trusted Siemens 3TB series, known for its long service life and exceptional performance.

Key Features & Benefit

• Reliable AC Control: Specifically rated for AC 60 Hz and a 110 V AC coil voltage, this contactor provides stable and consistent performance for a variety of applications.
• High Switching Capacity: Capable of handling loads up to 9A at AC-3 400V (4kW), making it suitable for standard motor control applications.
• Integrated Auxiliary Contacts: Features a built-in configuration of 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contact, providing flexibility for signaling, interlocking, and control circuit applications without the need for additional modules.
• Space-Efficient Size 0 Design: Its compact "Size 0" footprint allows for efficient use of space within control panels and electrical cabinets, simplifying installation and layout.
• Secure Screw Connection: Equipped with secure screw terminals, ensuring a reliable and vibration-resistant electrical connection. This design simplifies wiring and maintenance.
• Siemens Quality: Manufactured by Siemens, a global leader in industrial automation, guaranteeing a product that meets the highest standards of quality, safety, and performance.

Technical Specification

• Product Type: Contactor
• Model Number: 3TB4022-0XG1
• Series: Siemens 3TB
• Coil Voltage: 110 V AC
• Frequency: 60 Hz
• Operational Current (AC-3): 9 A at 400 V
• Operational Power (AC-3): 4 kW
• Auxiliary Contacts: 1 NO + 1 NC
• Size: Size 0
• Connection Type: Screw terminals
• Mounting: Standard DIN rail or screw mounting

Function

The Siemens 3TB4022-0XG1 contactor serves as an electrically operated switch for controlling a power circuit. Its primary function is to safely and remotely switch a high-power load (such as a motor) on or off using a low-power control signal from the 110V AC coil. The integrated auxiliary contacts allow for the creation of feedback loops or interlocking circuits to ensure the correct and safe sequence of operations.
